Identification
16 P100011294 E
3 Identification
3.1 Name plate
The name plate of the wireless connection module on the left side. The name
plate of the wireless room thermostat is at the backside and on the inside of
the front panel.
a)
b)
B12239a
c)
_/_05...06 230 V 2,5 (1) A
Channel 1…4: 24 V, 0,7 A / Channel
868 MHz IP20
1135006441
17466393.004
Touchline Controller - 4 Ch
24 V AC +/-15%
_/_07...08 230 V 2,5 (1) A
ROTH WERKE GMBH Am Seerain 2, 35232 Dautphetal
Swiss Made
B9999
2x1,5 V AAA 868 MHz
1135006444
17466393.100
Touchline ROU
Swiss Made
B9999
ROTH WERKE GMBH Am Seerain 2, 35232 Dautphetal
230 V AC +/- 10% 868 MHz
1135006445
17466393.110
Touchline ROU
Swiss Made
B9999
ROTH WERKE GMBH Am Seerain 2, 35232 Dautphetal
Fig. 1: Name plate a) wireless connection module, b) wireless room thermostat,
c) wireless room thermostat, 230 V
3.2 Types (part numbers of product range)
3.2.1 Wireless connection module
Type Material numbers
Europe Nordic Denmark Sweden Norway Finland
4 Channel
with LAN
1135006441 17466393.004 466393.004 2420667 8357507 2070885
8 Channel
with LAN
1135006442 17466393.008 466393.008 2420668 8357508 2070886
12 Channel
with LAN
1135006443 17466393.012 466393.012 2420669 8357509 2070887
4 Channel
without LAN
1135007344 17466393.054 466393.054 2432986 8357659 2070899
8 Channel
without LAN
1135007345 17466393.058 466393.058 2432987 8357661 2070900
12 Channel
without LAN
1135007346 17466393.062 466393.062 2432988 8357662 2070901
Table 1: Material numbers wireless connection module
