User Manual Roth EnergyLogic Touchline/Wireless
Technical data
114 P100011294 E
Dimensions(width x height x depth)
Dimensions connection module without
transformer
● 4-channel: 225 mm x 74 mm x 52 mm
● 8-channel: 290 mm x 74 mm x 52 mm
● 12-channel: 355 mm x 74 mm x 52 mm
● Transformer: 78 mm x 74 mm x 52 mm
Weight incl. transformer
● 4-channel: 1.3 kg
● 8- channel: 1.5 kg
● 12- channel: 1.7 kg
Cable retention Meander shape
Monitoring LEDs
14.2.2 Electrical connections
Power supply wireless connection
module
24 V AC  15% via separate 230 V/24 V 50/60 Hz transformer
Fuse Internal, self-resetting (not exchangeable)
Power source 24 V External transformer with cable 230 V AC
Power consumption at 24 V, transformer
included, without thermal actuators,
4-, 8- or 12-channel version
2.6 W
Power consumption in operation
● 4-channel: max. 27 W
● 8-channel: max. 40 W
● 12-channel: max. 60 W
Power consumption is depending on the number of actuator that is
connected.
Max. current at stand-by 200 mA / 250 mA
Max. number of thermal actuators
● 4-channel: 6 (2 channels / 2 actuators, 2 channels / 1 actuator)
● 8-channel: 12 (4 channels / 2 actuators, 4 channels / 1 actuator)
● 12-channel: 18 (6 channels / 2 actuators, 6 channels / 1 actuator)
Protection class II (EN60730)
14.2.3 Inputs
C/O
1)
Contact recognition, low voltage from wireless connection module
Eco (N/R) Contact recognition, low voltage from wireless connection module
Dew-point monitoring
1)
Contact recognition, low voltage from wireless connection module
C/O in-/TB-input
1)
General input 24 to 230 V
1) Only for wireless connection modules with LAN
