User Manual Roth EnergyLogic Touchline/Wireless
Commissioning and operation
P100011294 E 57
NOTE
All central plant devices such as a central pump, burner control, C/O-signal
for a heat pump etc. are connected to the wireless connection module
"Master". To a wireless connection module "Slave" only a local pump, if
any, is connected.
For the configuration of the relevant parameters P-51, P-61, P62 und
P-63 see parameter description page 92, chapter 9.3.6 and page 94, chap-
ter 9.3.7.
7.1.7 Internal system grid repeater
If the distance between a wireless connection module "Slave" and the associ-
ated wireless connection module "Master" prevents a direct wireless connec-
tion, an interim wireless connection module "Slave" can be used as a repeat-
er. This way, the system network's reach can be enlarged without using an
external repeater. The internal system network repeater does not influence the
room thermostat networks.
NOTE
Only one repeater in the form of an external or internal repeater must be
activated per system network.
NOTE
In order to activate the internal repeater, the wireless connection module
must be configured as a Slave and assigned to a wireless connection
module "Master".
Activate the
internal repeater
► Press push button Zone of the wireless connection module for at least
10 seconds.
► After a short time, the LED Master will blink quickly.
► After 10 seconds, the LED Master blinks once if the wireless connection is
good. If the wireless connection is bad, the LED blinks twice.
► The internal repeater is activated.
Deactivate the
internal repeater
► Press push button Zone at the wireless connection module for at least
10 seconds.
► After a short time, the LED Master will blink quickly.
► After 10 seconds, the LED Master goes out.
► The internal repeater is deactivated.
