User Manual Roth EnergyLogic Touchline/Wireless
Plant examples and communication
P100011294 E 121
16 Plant examples and communication
16.1 Plant examples with one wireless connection module
B12263a
CH 1
CH 2 CH 3 CH 4 CH 5 CH 6 CH 7 CH 8
2 31
Fig. 58: Radio channel group with equal priority
1 Radio channel group 1
2 Radio channel group 2
3 Single addressing
CH 1…CH 8: radio-channels
B12264a
SENS
3
CH 1
CH 2 CH 3 CH 4 CH 5 CH 6 CH 7 CH 8
2
1
SENS SENS
Fig. 59: Radio channel groups with equal priority and average temperature building
1 Radio channel group 1
2 Radio channel group 2 with average temperature building
3 Single addressing
CH 1…CH 8: radio-channels
SENS: wireless room thermostat Sensor mode,
 see page 53, chapter 53.
