Install bottom part
► Install the bottom part of the wireless room thermostat.
60 mm
60 mm
Fig. 19: Install lower part
Insert batteries
► Insert the batteries in the upper part of the wireless room thermostat.
Fig. 20: Insert batteries
Close wireless room
thermostat
5
20
30
click
5
20
30
Fig. 21: Close wireless room thermostat
