User Manual Roth EnergyLogic Touchline/Wireless
Table of Content
4 P100011294 E
5 Installation ........................................................................................... 30
5.1 Wireless connection module ...................................................... 30
5.2 Wireless room thermostat........................................................... 31
5.2.1 Place of installation and general installation notes ........ 31
5.2.2 Wireless room thermostat with display .......................... 32
5.2.3 Wireless room thermostat without display ..................... 34
5.2.4 Wireless room thermostat with 230 V connection .......... 36
6 Electrical connections ........................................................................ 38
6.1 Safety.......................................................................................... 38
6.2 General wiring notes ................................................................... 38
6.3 Wireless connection module ...................................................... 40
6.3.1 Connection diagram
for wireless connection module with LAN ...................... 40
6.3.1 Connection diagram
for wireless connection module without LAN ................. 41
6.3.2 Perform electrical connections ....................................... 41
7 Commissioning and operation .......................................................... 51
7.1 Addressing .................................................................................. 51
7.1.1 Address one wireless room thermostat
to one radio channel ....................................................... 52
7.1.2 Address one wireless room thermostats
to several radio channels ............................................... 52
7.1.3 Address several wireless room thermostats
to one radio channel (sensor mode) .............................. 53
7.1.4 Test addressing .............................................................. 55
7.1.5 Delete addressing .......................................................... 55
7.1.6 Combine several wireless connection modules
into a system .................................................................. 56
7.1.7 Internal system grid repeater ......................................... 57
7.2 Zones .......................................................................................... 59
7.2.1 Zone building, assign radio channels to one zone ......... 59
7.2.2 Delete assignment of a radio channel or several radio
channels to a zone ......................................................... 60
7.3 Change setpoints ........................................................................ 61
7.3.1 Set room temperature .................................................... 61
7.3.2 Set floor temperature ..................................................... 61
7.4 Select mode of operation ........................................................... 62
7.5 Set time and date ....................................................................... 64
