User Manual Roth EnergyLogic Touchline/Wireless
Commissioning and operation
P100011294 E 63
► Press the sensor button , to confirm the new mode of operation.
– If no sensor button is pressed, the selection is interrupted after 10 sec-
onds and the wireless room thermostat returns into stand-by mode. The
new mode of operation is not saved.
– Press the sensor button
, to interrupt the procedure. The new mode
of operation is not saved.
NOTE
The modes of operation heating and cooling are only selectable if the wire-
less room thermostat has the priority over the C/O input.
If a wireless room thermostat has been defined as master, then heating
and cooling can only be selected with the master wireless room thermo-
stat.
For the configuration of the relevant parameters P-48 and P-51 see
parameter description page 91 and page 92.
NOTE
When the operating mode "Off (frost protection)" was selected, the display
switches from sleep mode to operating mode and the display shows the
set value for parameter P-32. In cooling operation, the display shows
"OFF" when switching from sleeping mode to operating mode. The buttons
and are not active.
Select and change time
program
See page 65, chapter 7.6.
NOTE
If a time program is activated it is possible to manually override the mode
of operation determined by the time program. At the next switching point of
the time program, the manual override is deactivated again by the time
program. However, if "Off (frost protection)" has been selected, the mode
of operation will remain "Off (frost protection)" at any time.
In order to permanently operate the wireless room thermostat manually,
the time program must be deactivated.
