Fig. 5 - Engagement of AGROSHIFT with LOW range selected.
Fig. 6 - Diagram showing engagement of AGROSHIFT with HIGH range selected.
clutch transmission
agroshift
Parts in movement
In rotation (idling)
Parts locked to transmission housing
Parts locked to epicyclic speed reducer
Oil circuit for operation of clutches
Oil circuit for operation of clutches
27
2
121
