transmission
power take-off
Specifications
P.T.O clutch
clutch multidisk, oil-bath clutch with axial piston
number of clutch disks 5
diameter of clutch disks 124.5
thickness of assembled friction discs minimum mm 26
maximum mm 27.75
number of intermediate discs 5
disc lubrication pressure bar 2 to 3
P.T.O. clutch relief pressure setting bar 12
0
+ 2
P.T.O. pressure control valve bar 18
restrictor valve mm 3
brake apply cylinder free travel minimum mm 2.8
maximum mm 3.6
directional control valve spool travel mm 18
Spring specifications
piston return spring 2.4019.373.1
diameter of wire mm 6.5
external diameter mm 79.5
spring relaxed mm 61.5
spring compressed kg 75 (735 N) mm 30
kg 79 (782 N) mm 28
36
3
170
