SAME SILVER 80 - Installing the Ring-Feeders

Fig. 9 - "RING-FEEDER" rings installed.
Installing "RING-FEEDER" rings
Install all the parts following the order shown in figure.
Thoroughly tighten the pulley hub on engine crankshaft to 34
±
1.5
kgm (333
±
15 Nm).
Fig. 10 - Frront PTO assembly parts..
59
5
vehicle
front power take-off
290
