SAME SILVER 80 - Electrical System; Specifications and Components

General specifications
The electrical system is fully equipped for use on the road, with sidelights, main/dipped beam headlamps, direction
indicators doubling as hazard warning lights, and work lights, all fully in compliance with legal requirements as
embodied in the highway code.
There are four essential components and assemblies: battery, alternator, starter motor, and auxiliaries.
The system operates at a nominal 12 Volts (the maximum voltage in operation is 14,3
±
0,5 V).
The battery charge level is indicated by a relative meter on the instrument panel.
Technical specifications
battery
type maintenance free
voltage V 12
discharge capacity over 20 hours Ah 120 (176 or 180 Ah in cold climates)
rated current A 500 (650 or 750 A in cold climates)
starter motor
p/n 2.9619.340.0 (MARELLI)
2.9619.290.0 (BOSCH)
2.9619.350.0 (ISKRA)
voltage V 12
nominal rated power HP 4 approx (3 kW approx)
electromagnetic control with bendix type pinion engagement
alternator
RECHARGE SYSTEM
p/n 65A 2.9439.390.0
85A 2.9439.450.0
HEATING SYSTEM 65A 2.9439.480.0
85A 2.9439.470.0
type three-phase
nominal rated voltage V 12
pulley nut tightening torque Nm 62 (5,5 kgm)
systems
electrical system
84
8
399
