Fig. 11 - Cooling system.
engine
cooling system - specifications
The cooling system consists of a ventilation unit composed by a fan, a stator and an air conveyor.
This system ensures high thermodynamic efficiency as well as prompt engine power availability after a cold start.
fan with aluminium blades
fan diameter mm 320
fan blade number 13
1
21
