The DATA MONITOR is located on the driver’s instrument panel.
This unit displays various information concerning the tractor (speed, rpm, wheel slip, etc.) and performs work quantity
calculations.
The data display provides data concerning tractor operations, and allows the operator to read and also vary the function
parameters of the electronic control unit.
The DATA MONITOR is enclosed in a plastic housing. The front panel features a 128 x 64 pixel graphic display and
10 pushbuttons, and is tilted towards the operator to facilitate read-out.
Both the display and the keypad are illuminated for use at night.
A 20 pin connector for hooking up to the electric circuit of the tractor is situated on the rear panel of the unit, which is
also connected to a series of sensors and electronic control units installed on the tractor.
The system has two distinct functions:
— as a tractor DATA MONITOR
— as a data terminal for connection to the control unit.
DATA MONITOR
The monitor displays the following data:
Engine speed
Vehicle speed
PTO speed
Ploughing depth
Wheel slide
Distance covered
Ploughing area
Work time
Each function (excepting slide which is constantly displayed) is selected by pressing a specific pushbutton. The last
three listed functions can be reset by pressing the Reset button.
Data concerning area worked and work time are updated only when the implement connected to the rear lift is in
operating position (i.e. below the pre-set limit).
Many functions are available in either the metric or the imperial system, according to preference. The measurement
system used is displayed next to the read-out and symbol.
An icon reproducing the symbol on the select buttons helps the operator to identify the function data displayed.
