Setting the maximum speed to 30 km/h
When so required by local regulations, the maximum speed can be limited to 30 km/h by means of the engine control
unit and a vehicle speed sensor mounted on the gearbox.
The maximum speed is set as follows:
— Connect the "ALL ROUND TESTER" and calibrate the engine speed following the normal procedure.
— Call up the main menu and press button 4 “MANUAL PROGRAMMING” , enter the password (supplied by our
technician), consult the table below to find the correct parameter for the rear tyres fitted to the tractor, and then select
this parameter using the keypad.
Press C to confirm the selection, and then press E twice to exit the programme.
Checking the calibration.
With the tractor stationary, check that the engine speed reaches the maximum rpm;
Then, with the tractor moving, engage top gear and accelerate to maximum speed; in this condition the engine speed
should be between 1700 and 1900 rpm.
NB: the control unit’s diagnostic procedure includes the alarm “speed sensor faulty or not connected”. This alarm
is signalled with six flashes of the LED on the hand throttle.
SILVER 80-90-100.4-100.6
1
st
version (see the serial number at pag. 133)
80-90-100.4 CV 100.6 CV
Pneus Parameter Pneus Parameter
16.9 x 34 5483 14.9 R 38 5351
16.9 R 34 5483 480 / 70 R 34 5494
18.4 R 30 5673 520 / 70 R 34 5316
18.4 R 34 5305 16.9 R 38 5149
13.6 R 38 5520 480 / 70 R 38 5149
480 / 70 R 34 5483
14.9 R 38 5340
520 / 70 R 34 5305
SILVER 80-90-100.4-100.6
2
nd
version (see the serial number at pag. 133)
80-90-100.4 CV 100.6 CV
Pneus Parameter Pneus Parameter
16.9 x 34 4639 14.9 R 38 4527
16.9 R 34 4639 480 / 70 R 34 4648
18.4 R 30 4800 520 / 70 R 34 4498
18.4 R 34 4480 16.9 R 38 4356
13.6 R 38 4670 480 / 70 R 38 4356
480 / 70 R 34 4639
14.9 R 38 4518
520 / 70 R 34 4480
engine
fuel system
16
1
73
