SAMSUNG Installation
DCS-816 February, 1999
3-1
PART 3. INSTALLING OPTION CARDS AND TRUNK CARDS
(Figure 3-1)
Unpack and inspect each card before installing. Check for signs of physical damage. If any
damage is detected, do not attempt to install. Contact the local distributor for advice immediately.
The DCS-816 system has one (1) trunk expansion slot for a trunk card and two (2) option
connections for SIO and AA. See Figure 3-1.
INSTALLING OPTION CARDS AND A TRUNK CARD
FIGURE 3-1
