7-1-2. GP-IB Function
GP-IB has 10 kinds of interface functions, each of which has its grade that is called its
subset. A "0" after the symbol of each function shows that support is not made, and
each numeric value represents grade.
1) GPIB address
GP-IB address of this product can be changed to refer to “ 7-1-3 Setting the
address, delimiter, and command set”. The changed address will be available after
setting. The changed address are saved in internal memory.
2) LOCAL
LOCAL is a state that this product is controlled by a key operation. This state is valid
for all key operations.
3) REMOTE
REMOTE is a state that this product is controlled from other controllers through GPIB
bus. In this state, the all key operations is disable except for LOCAL key and LD key.
4) Device Clear(DCL)
When this product receives the universal command “DCL” in REMOTE state, the
transmit and receive buffers are cleared.
Symbol Function TSL-710 Subset
SH Source handshake SH1: All functions
AH Acceptor handshake AH1: All functions
T Talker T8: Basic talker, talker release by MLA
L Listener L4: Basic listener, listener release by MTA
SR Service request SR1: All functions
RL Remote/Local
RL2: Remote/local function, no local lockout
function
PP Parallel poll PP0: none
DT Device trigger DT0: none
DC Device clear DC1: All functions
C Controller C0: none
CAUTION
Do not disconnect or connect a cable from and to devices connected with GP-
IB cable, do not short-circuit connector, and do not turn ON/OFF the devices.
Otherwise, action may be stopped, error may occur, causing a failure. In the
event of trouble owing to these causes, reset all the connected devices, and
then activate the system once again.
When conguring a system, remove the unused device or unnecessary cable
and return to the original setup.
