Address Point ID Description Options/Range Units Type R/W Notes
47080-47083 V3 transformer correction
47084-47087 Reserved
47088-47091 I1 transformer correction
47092-47095 I2 transformer correction
47096-47099 I3 transformer correction
Local Settings
46400-46415
+0 Local time offset, min 0-+/-720 min INT16 R/W
+1 Daylight savings time (DST) option 0=DST disabled (standard time
only), 1=DST enabled
UINT16 R/W
+2 DST start month 1-12 UINT16 R/W
+3 DST start week of the month 1=1st, 2=2nd, 3=3rd, 4=4th week,
5=the last week of the month
UINT16 R/W
+4 DST start weekday 1-7 (1=Sun, 7=Sat) UINT16 R/W
+5 DST end month 1-12 UINT16 R/W
+6 DST end week of the month 1=1st, 2=2nd, 3=3rd, 4=4th week,
5=the last week of the month
UINT16 R/W
+7 DST end weekday 1-7 (1=Sun, 7=Sat) UINT16 R/W
+8 Clock synchronization source 1-4 = DI1-DI4, 32767 = meter
clock
UINT16 R/W A DI input is considered a pulse or
KYZ input. The pulse edge adjusts
the clock at the nearest whole
minute.
+9 Country code ITU country calling code UINT16 R/W
+10 DST start hour 1-6 UINT16 R/W
+11 DST end hour 1-6 UINT16 R/W
+12-15 Reserved UINT16 R/W
Clock Indication and Setup
46416-46447
+0,1 Local time, in seconds, since Jan 1, 1970 F1 sec UINT32 R/W
+2,3 Fractional seconds, µsec µsec UINT32 R/W
+4 Fractional seconds, milliseconds 0-999 ms UINT16 R/W
+5 Seconds 0-59 UINT16 R/W
+6 Minutes 0-59 UINT16 R/W
+7 Hour 0-23 UINT16 R/W
+8 Day of month 1-31 UINT16 R/W
+9 Month 1-12 UINT16 R/W
+10 Year (calendar year minus 2000) 0-99 UINT16 R/W
+11 Weekday 1-7 (1=Sun, 7=Sat) UINT16 R
+12 Daylight savings time status 0=standard time is active,
1=daylight savings time is active
UINT16 R
+13-31 Reserved UINT16
