Address Point ID Description Options/Range Units Type R/W Notes
Fault Log Recording Setup
52278-52341 V24.3.1 and higher
+0 Log options, bitmap Bit 0 – waveform log on event start:
0 = disabled, 1 = enabled;
Bit 1 – waveform log on event end:
0 = disabled, 1 = enabled;
Bit 2 – recording to PQ log:
1 = disabled
UINT16 R/W
+1 Waveform log number 0-1 = log #1-#2 UINT16 R/W
+2 Data/RMS plot option 0 (N/A) UINT16 R
+3 Data log number (factory preset) 0 (N/A) UINT16 R
+4 1/2-cycle RMS plot, cycles before event 0 (N/A) cycle UINT16 R
+5 1/2-cycle RMS plot, cycles after event 0 (N/A) cycle UINT16 R
+6 1/2-cycle RMS plot duration, cycles 0 (N/A) cycle UINT16 R
+7-63 Reserved UINT16 R
File Setup
52598-53877
+0 File type 0 UINT16 R/W
+1 File attributes (bitmap) F3 UINT16 R/W
+2 Number of records in the file 0-65535 (0 = delete file) UINT16 R/W
+3 Number of sections/channels in the file 0-32 UINT16 R/W 0 = non-partitioned file
+4 Number of parameters per section record 1-16 UINT16 R/W
+5 Not used 0 UINT16 R/W
+6 Section record size, bytes (for info only) UINT16 R
+7 File record size, bytes (for info only) UINT16 R
+8, 9 Allocated file size, bytes (for info only) UINT32 R
52598-52607 Event Log Setup
52608-52617 Data Log #1 Setup
52618-52627 Data Log #2 Setup
52628-52637 Data Log #3 Setup
52638-52647 Data Log #4 Setup
52648-52657 Data Log #5 Setup
52658-52667 Data Log #6 Setup
52668-52677 Data Log #7 Setup
52678-52687 Data Log #8 Setup
52688-52697 Data Log #9 Setup
52698-52707 Data Log #10 Setup
52708-52717 Data Log #11 Setup
52718-52727 Data Log #12 Setup
52728-52737 Data Log #13 Setup
52738-52747 Data Log #14 Setup
52748-52757 Data Log #15 Setup
52758-52767 Data Log #16 Setup
