Satec PM174 User Manual

24
Address Point ID Description
Low and High Scales
3
Units
3
Type R/W Notes
+1 0x1081 V2/V23 Voltage magnitude 0-Vmax U1 UINT16 R
2
+2 0x1082 V3/V31 Voltage magnitude 0-Vmax U1 UINT16 R
2
+3 0x1083 Not used UINT16 R
+4 0x1084 I1 Current magnitude 0-Imax U2 UINT16 R
+5 0x1085 I2 Current magnitude 0-Imax U2 UINT16 R
+5 0x1086 I3 Current magnitude 0-Imax U2 UINT16 R
+7 0x1087 Not used UINT16 R
+8 0x1088 V1/V12 Voltage angle -180.0-180.0 0.1º INT16 R
2
+9 0x1089 V2/V23 Voltage angle -180.0-180.0 0.1º INT16 R
2
+10 0x108A V3/V31 Voltage angle -180.0-180.0 0.1º INT16 R
2
+11 0x108B Not used INT16 R
+12 0x108C I1 Current angle -180.0-180.0 0.1º INT16 R
+13 0x108D I2 Current angle -180.0-180.0 0.1º INT16 R
+14 0x108E I3 Current angle -180.0-180.0 0.1º INT16 R
+15 0x108F Not used INT16 R
4672-4704 1-Second Phase Values
+0 0x1100 V1/V12 Voltage 0-Vmax U1 UINT16 R
1
+1 0x1101 V2/V23 Voltage 0-Vmax U1 UINT16 R
1
+2 0x1102 V3/V31 Voltage 0-Vmax U1 UINT16 R
1
+3 0x1103 I1 Current 0-Imax U2 UINT16 R
+4 0x1104 I2 Current 0-Imax U2 UINT16 R
+5 0x1105 I3 Current 0-Imax U2 UINT16 R
+6 0x1106 kW L1 -Pmax-Pmax U3 INT16 R
+7 0x1107 kW L2 -Pmax-Pmax U3 INT16 R
+8 0x1108 kW L3 -Pmax-Pmax U3 INT16 R
+9 0x1109 kvar L1 -Pmax-Pmax U3 INT16 R
+10 0x110A kvar L2 -Pmax-Pmax U3 INT16 R
+11 0x110B kvar L3 -Pmax-Pmax U3 INT16 R
+12 0x110C kVA L1 0-Pmax U3 UINT16 R
+13 0x110D kVA L2 0-Pmax U3 UINT16 R
+14 0x110E kVA L3 0-Pmax U3 UINT16 R
+15 0x110F Power factor L1 -1.000-1.000 0.001 INT16 R
+16 0x1110 Power factor L2 -1.000-1.000 0.001 INT16 R
+17 0x1111 Power factor L3 -1.000-1.000 0.001 INT16 R
+18 0x1112 V1/V12 Voltage THD 0-999.9 0.1% UINT16 R
2, 6
+19 0x1113 V2/V23 Voltage THD 0-999.9 0.1% UINT16 R
2, 6
+20 0x1114 V3/V31 Voltage THD 0-999.9 0.1% UINT16 R
2, 6
+21 0x1115 I1 Current THD 0-999.9 0.1% UINT16 R
6
+22 0x1116 I2 Current THD 0-999.9 0.1% UINT16 R
6
+23 0x1117 I3 Current THD 0-999.9 0.1% UINT16 R
6
+24 0x1118 I1 K-Factor 1.0-999.9 0.1 UINT16 R
6
+25 0x1119 I2 K-Factor 1.0-999.9 0.1 UINT16 R
6
+26 0x111A I3 K-Factor 1.0-999.9 0.1 UINT16 R
6
