Satec PM174 User Manual

44
Address Point ID Description
Options/Range
3
Units
3
Type R/W Notes
+44,45 0x3416 I2 Current THD 0-9999
×0.1%
UINT32 R
5
+46,47 0x3417 I3 Current THD 0-9999
×0.1%
UINT32 R
5
+48,49 0x3418 I1 K-Factor 10-9999
×0.1
UINT32 R
5
+50,51 0x3419 I2 K-Factor 10-9999
×0.1
UINT32 R
5
+52,53 0x341A I3 K-Factor 10-9999
×0.1
UINT32 R
5
+54,55 0x341B I1 Current TDD 0-1000
×0.1%
UINT32 R
5
+56,57 0x341C I2 Current TDD 0-1000
×0.1%
UINT32 R
5
+58,59 0x341D I3 Current TDD 0-1000
×0.1%
UINT32 R
5
18560-18567 Maximum 1-Cycle Total Values
+0,1 0x3500 Total kW -Pmax-Pmax U3 INT32 R
+2,3 0x3501 Total kvar -Pmax-Pmax U3 INT32 R
+4,5 0x3502 Total kVA 0-Pmax U3 UINT32 R
+6,7 0x3503 Total PF 0-1000
×0.001
UINT32 R Absolute value
18688-18693 Maximum 1-Cycle Auxiliary Values
+0,1 0x3600 Not used UINT32 R
+2,3 0x3601 In Current 0-Imax U2 UINT32 R
+4,5 0x3602 Frequency 0-Fmax
×0.01Hz
UINT32 R
18816-18849 Maximum Demands
+0,1 0x3700 V1/V12 Maximum volt demand 0-Vmax U1 UINT32 R
2
+2,3 0x3701 V2/V23 Maximum volt demand 0-Vmax U1 UINT32 R
2
+4,5 0x3702 V3/V31 Maximum volt demand 0-Vmax U1 UINT32 R
2
+6,7 0x3703 I1 Maximum ampere demand 0-Imax U2 UINT32 R
+8,9 0x3704 I2 Maximum ampere demand 0-Imax U2 UINT32 R
+10,11 0x3705 I3 Maximum ampere demand 0-Imax U2 UINT32 R
+12,13 0x3706 Not used UINT32 R
+14,15 0x3707 Not used UINT32 R
+16,17 0x3708 Not used UINT32 R
+18,19 0x3709 Maximum kW import sliding window demand 0-Pmax U3 UINT32 R
+20,21 0x370A Maximum kvar import sliding window demand 0-Pmax U3 UINT32 R
+22,23 0x370B Maximum kVA sliding window demand 0-Pmax U3 UINT32 R
+24,25 0x3737 Not used UINT32 R
+26,27 0x370D Not used UINT32 R
+28,29 0x370E Not used UINT32 R
+30,31 0x370F Maximum kW export sliding window demand 0-Pmax U3 UINT32 R
+32,33 0x3710 Maximum kvar export sliding window demand 0-Pmax U3 UINT32 R
19008-19031 Maximum Harmonic Demands
+0,1 0x3880 V1/V12 THD demand 0-9999
×0.1%
UINT32 R
2
+2,3 0x3881 V2/V23 THD demand 0-9999
×0.1%
UINT32 R
2
+4,5 0x3882 V3/V31 THD demand 0-9999
×0.1%
UINT32 R
2
+6,7 0x3883 Not used UINT32 R
+8,9 0x3884 I1 THD demand 0-9999
×0.1%
UINT32 R
+10,11 0x3885 I2 THD demand 0-9999
×0.1%
UINT32 R
+12,13 0x3886 I3 THD demand 0-9999
×0.1%
UINT32 R
