Satec PM174 User Manual

83
3.10 Billing/TOU Daily Profile Data Log
File
Channel/
Section
1
Record
Field No.
2
Point Label Point
ID
Description Range
Units
3
Type Notes
0/0 Energy Register #1
1 REG1 0x1780 Summary (total) energy reading 0-999,999,999 1 kWh UINT32
2 TRF1 0x7000 Tariff #1 energy reading 0-999,999,999 1 kWh UINT32
3 TRF2 0x7001 Tariff #2 energy reading 0-999,999,999 1 kWh UINT32
4 TRF3 0x7002 Tariff #3 energy reading 0-999,999,999 1 kWh UINT32
5 TRF4 0x7003 Tariff #4 energy reading 0-999,999,999 1 kWh UINT32
6 TRF5 0x7004 Tariff #5 energy reading 0-999,999,999 1 kWh UINT32
7 TRF6 0x7005 Tariff #6 energy reading 0-999,999,999 1 kWh UINT32
8 TRF7 0x7006 Tariff #7 energy reading 0-999,999,999 1 kWh UINT32
9 TRF8 0x7007 Tariff #8 energy reading 0-999,999,999 1 kWh UINT32
… …
7/7 Energy Register #8
1 REG8 0x1787 Summary (total) energy reading 0-999,999,999 1 kWh UINT32
2 TRF1 0x7000 Tariff #1 energy reading 0-999,999,999 1 kWh UINT32
3 TRF2 0x7001 Tariff #2 energy reading 0-999,999,999 1 kWh UINT32
4 TRF3 0x7002 Tariff #3 energy reading 0-999,999,999 1 kWh UINT32
5 TRF4 0x7003 Tariff #4 energy reading 0-999,999,999 1 kWh UINT32
6 TRF5 0x7004 Tariff #5 energy reading 0-999,999,999 1 kWh UINT32
7 TRF6 0x7005 Tariff #6 energy reading 0-999,999,999 1 kWh UINT32
8 TRF7 0x7006 Tariff #7 energy reading 0-999,999,999 1 kWh UINT32
9 TRF8 0x7007 Tariff #8 energy reading 0-999,999,999 1 kWh UINT32
16/8 Daily Maximum Demand Register #1
1 REG1 MD 0x4780 Summary (total) max. demand reading 0-Pmax U3 UINT32
2 TRF1 MD 0x7100 Tariff #1 max. demand reading 0-Pmax U3 UINT32
3 TRF2 MD 0x7101 Tariff #2 max. demand reading 0-Pmax U3 UINT32
4 TRF3 MD 0x7102 Tariff #3 max. demand reading 0-Pmax U3 UINT32
5 TRF4 MD 0x7103 Tariff #4 max. demand reading 0-Pmax U3 UINT32
6 TRF5 MD 0x7104 Tariff #5 max. demand reading 0-Pmax U3 UINT32
7 TRF6 MD 0x7105 Tariff #6 max. demand reading 0-Pmax U3 UINT32
8 TRF7 MD 0x7106 Tariff #7 max. demand reading 0-Pmax U3 UINT32
9 TRF8 MD 0x7107 Tariff #8 max. demand reading 0-Pmax U3 UINT32
… …
23/15 Daily Maximum Demand Register #8
1 REG8 MD 0x4787 Summary (total) max. demand reading 0-Pmax U3 UINT32
2 TRF1 MD 0x7100 Tariff #1 max. demand reading 0-Pmax U3 UINT32
3 TRF2 MD 0x7101 Tariff #2 max. demand reading 0-Pmax U3 UINT32
4 TRF3 MD 0x7102 Tariff #3 max. demand reading 0-Pmax U3 UINT32
5 TRF4 MD 0x7103 Tariff #4 max. demand reading 0-Pmax U3 UINT32
