Satec PM174 User Manual

23
Address Point ID Description
Low and High Scales
3
Units
3
Type R/W Notes
+12 0x0C0C kVA L1 0-Pmax U3 UINT16 R
+13 0x0C0D kVA L2 0-Pmax U3 UINT16 R
+14 0x0C0E kVA L3 0-Pmax U3 UINT16 R
+15 0x0C0F Power factor L1 -1.000-1.000 0.001 INT16 R
+16 0x0C10 Power factor L2 -1.000-1.000 0.001 INT16 R
+17 0x0C11 Power factor L3 -1.000-1.000 0.001 INT16 R
+18 0x0C12 V1/V12 Voltage THD 0-999.9 0.1% UINT16 R
2, 5
+19 0x0C13 V2/V23 Voltage THD 0-999.9 0.1% UINT16 R
2, 5
+20 0x0C14 V3/V31 Voltage THD 0-999.9 0.1% UINT16 R
2, 5
+21 0x0C15 I1 Current THD 0-999.9 0.1% UINT16 R
5
+22 0x0C16 I2 Current THD 0-999.9 0.1% UINT16 R
5
+23 0x0C17 I3 Current THD 0-999.9 0.1% UINT16 R
5
+24 0x0C18 I1 K-Factor 1.0-999.9 0.1 UINT16 R
5
+25 0x0C19 I2 K-Factor 1.0-999.9 0.1 UINT16 R
5
+26 0x0C1A I3 K-Factor 1.0-999.9 0.1 UINT16 R
5
+27 0x0C1B I1 Current TDD 0-100.0 0.1% UINT16 R
5
+28 0x0C1C I2 Current TDD 0-100.0 0.1% UINT16 R
5
+29 0x0C1D I3 Current TDD 0-100.0 0.1% UINT16 R
5
+30 0x0C1E V12 Voltage 0-Vmax U1 UINT16 R
+31 0x0C1F V23 Voltage 0-Vmax U1 UINT16 R
+32 0x0C20 V31 Voltage 0-Vmax U1 UINT16 R
4416-4428 1-Cycle Total Values
+0 0x0F00 Total kW -Pmax-Pmax U3 INT16 R
+1 0x0F01 Total kvar -Pmax-Pmax U3 INT16 R
+2 0x0F02 Total kVA 0-Pmax U3 UINT16 R
+3 0x0F03 Total PF -1.000-1.000 0.001 INT16 R
+4 0x0F04 Total PF lag 0-1.000 0.001 UINT16 R
+5 0x0F05 Total PF lead 0-1.000 0.001 UINT16 R
+5 0x0F06 Total kW import 0-Pmax U3 UINT32 R
+7 0x0F07 Total kW export 0-Pmax U3 UINT32 R
+8 0x0F08 Total kvar import 0-Pmax U3 UINT32 R
+9 0x0F09 Total kvar export 0-Pmax U3 UINT32 R
+10 0x0F0A 3-phase average L-N/L-L voltage 0-Vmax U1 UINT32 R
1
+11 0x0F0B 3-phase average L-L voltage 0-Vmax U1 UINT32 R
+12 0x0F0C 3-phase average current 0-Imax U2 UINT32 R
4608-4612 1-Cycle Auxiliary Values
+0 0x1000 Not used UINT16 R
+1 0x1001 In (neutral) Current 0-Imax U2 UINT16 R
+2 0x1002 Frequency 0-Fmax 0.01Hz UINT16 R
+3 0x1003 Voltage unbalance 0-300.0 0.1% UINT16 R
+4 0x1004 Current unbalance 0-300.0 0.1% UINT16 R
4640-4655 Phasor
+0 0x1080 V1/V12 Voltage magnitude 0-Vmax U1 UINT16 R
2
