Satec PM174 User Manual

25
Address Point ID Description
Low and High Scales
3
Units
3
Type R/W Notes
+27 0x111B I1 Current TDD 0-100.0 0.1% UINT16 R
6
+28 0x111C I2 Current TDD 0-100.0 0.1% UINT16 R
6
+29 0x111D I3 Current TDD 0-100.0 0.1% UINT16 R
6
+30 0x111E V12 Voltage 0-Vmax U1 UINT16 R
+31 0x111F V23 Voltage 0-Vmax U1 UINT16 R
+32 0x1120 V31 Voltage 0-Vmax U1 UINT16 R
4864-4876 1-Second Total Values
+0 0x1400 Total kW -Pmax-Pmax U3 INT16 R
+1 0x1401 Total kvar -Pmax-Pmax U3 INT16 R
+2 0x1402 Total kVA 0-Pmax U3 UINT16 R
+3 0x1403 Total PF -1.000-1.000 0.001 INT16 R
+4 0x1404 Total PF lag 0-1.000 0.001 UINT16 R
+5 0x1405 Total PF lead 0-1.000 0.001 UINT16 R
+5 0x1406 Total kW import 0-Pmax U3 UINT32 R
+7 0x1407 Total kW export 0-Pmax U3 UINT32 R
+8 0x1408 Total kvar import 0-Pmax U3 UINT32 R
+9 0x1409 Total kvar export 0-Pmax U3 UINT32 R
+10 0x140A 3-phase average L-N/L-L voltage 0-Vmax U1 UINT32 R
1
+11 0x140B 3-phase average L-L voltage 0-Vmax U1 UINT32 R
+12 0x140C 3-phase average current 0-Imax U2 UINT32 R
4928-4932 1-Second Auxiliary Values
+0 0x1500 Not used UINT16 R
+1 0x1501 In (neutral) Current 0-Imax U2 UINT16 R
+2 0x1502 Frequency 0-Fmax 0.01Hz UINT16 R
+3 0x1503 Voltage unbalance 0-300.0 0.1% UINT16 R
+4 0x1504 Current unbalance 0-300.0 0.1% UINT16 R
4960-4971 Present Harmonic Demands
+0 0x1580 V1/V12 THD demand 0-999.9 0.1% UINT16 R
2
+1 0x1581 V2/V23 THD demand 0-999.9 0.1% UINT16 R
2
+2 0x1582 V3/V31 THD demand 0-999.9 0.1% UINT16 R
2
+3 0x1583 Not used UINT16 R
+4 0x1584 I1 THD demand 0-999.9 0.1% UINT16 R
+5 0x1585 I2 THD demand 0-999.9 0.1% UINT16 R
+5 0x1586 I3 THD demand 0-999.9 0.1% UINT16 R
+7 0x1587 Not used UINT16 R
+8 0x1588 I1 TDD demand 0-100.0 0.1% UINT16 R
+9 0x1589 I2 TDD demand 0-100.0 0.1% UINT16 R
+10 0x158A I3 TDD demand 0-100.0 0.1% UINT16 R
+11 0x158B Not used UINT16 R
4992-5021 Present Volt, Ampere and Power Demands
+0 0x1600 V1/V12 Volt demand 0-Vmax U1 UINT16 R
2
+1 0x1601 V2/V23 Volt demand 0-Vmax U1 UINT16 R
2
+2 0x1602 V3/V31 Volt demand 0-Vmax U1 UINT16 R
2
