Satec PM174 User Manual

48
Address Point ID Description
Options/Range
3
Units
3
Type R/W Notes
24576-24675 V1/V12 Harmonic Angles
2, 4
+0,1 0x6400
H01 Harmonic angle
-1800-1800
×0.1º
INT32 R
+2,3 0x6401
H02 Harmonic angle
-1800-1800
×0.1º
INT32 R
...
+98,99 0x6431
H50 Harmonic angle
-1800-1800
×0.1º
INT32 R
24704-24803 V2/V23 Harmonic Angles
2, 4
+0,1 0x6500
H01 Harmonic angle
-1800-1800
×0.1º
INT32 R
+2,3 0x6501
H02 Harmonic angle
-1800-1800
×0.1º
INT32 R
...
+98,99 0x6531
H50 Harmonic angle
-1800-1800
×0.1º
INT32 R
24832-24931 V3/V31 Harmonic Angles
2, 4
+0,1 0x6600
H01 Harmonic angle
-1800-1800
×0.1º
INT32 R
+2,3 0x6601
H02 Harmonic angle
-1800-1800
×0.1º
INT32 R
...
+98,99 0x6631
H50 Harmonic angle
-1800-1800
×0.1º
INT32 R
25088-25187 I1 Harmonic Angles
4
+0,1 0x6800
H01 Harmonic angle
-1800-1800
×0.1º
INT32 R
+2,3 0x6801
H02 Harmonic angle
-1800-1800
×0.1º
INT32 R
...
+98,99 0x6831
H50 Harmonic angle
-1800-1800
×0.1º
INT32 R
25216-25315 I2 Harmonic Angles
4
+0,1 0x6900
H01 Harmonic angle
-1800-1800
×0.1º
INT32 R
+2,3 0x6901
H02 Harmonic angle
-1800-1800
×0.1º
INT32 R
...
+98,99 0x6931
H50 Harmonic angle
-1800-1800
×0.1º
INT32 R
25344-25443 I3 Harmonic Angles
4
+0,1 0x6A00
H01 Harmonic angle
-1800-1800
×0.1º
INT32 R
+2,3 0x6A01
H02 Harmonic angle
-1800-1800
×0.1º
INT32 R
...
+98,99 0x6A31
H50 Harmonic angle
-1800-1800
×0.1º
INT32 R
25728-25771 10-Minute Volts and Symmetrical Components
+0, 1 0x6D00 V1 Voltage 0-Vmax U1 UINT32 R
2
+2, 3 0x6D01 V2 Voltage 0-Vmax U1 UINT32 R
2
+4, 5 0x6D02 V3 Voltage 0-Vmax U1 UINT32 R
2
+6-33 Reserved 0 UINT32 R
+34, 35 0x6D11 Zero-sequence voltage 0-Vmax U1 UINT32 R
+36, 37 0x6D12 Zero-sequence current 0-Imax U2 UINT32 R
+38, 39 0x6D13 Reserved 0 UINT32 R
+40, 41 0x6D14 Negative-sequence voltage unbalance 0-3000
×0.1%
UINT32 R
+42, 43 0x6D15 Negative-sequence current unbalance 0-3000
×0.1%
UINT32 R
