Satec PM174 User Manual

47
Address Point ID Description
Options/Range
3
Units
3
Type R/W Notes
20992-21023 Billing TOU Maximum Demand Register #1
+0,1 0x4800
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
+2,3 0x4801
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
+14,15 0x4807
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
21120-21135 Billing TOU Maximum Demand Register #2
+0,1 0x4900
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
+2,3 0x4901
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
+14,15 0x4907
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
21248-21263 Billing TOU Maximum Demand Register #3
+0,1 0x4A00
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
+2,3 0x4A01
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
+14,15 0x4A07
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
21056-21071 Billing TOU Maximum Demand Register #4
+0,1 0x4880
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
+2,3 0x4881
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
+14,15 0x4887
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
21184-21199 Billing TOU Maximum Demand Register #5
+0,1 0x4980
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
+2,3 0x4981
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
+14,15 0x4987
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
21312-21325 Billing TOU Maximum Demand Register #6
+0,1 0x4A80
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
+2,3 0x4A81
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
+14,15 0x4A87
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
22400-22415 Billing TOU Maximum Demand Register #7
+0,1 0x5300
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
+2,3 0x5301
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
+14,15 0x5307
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
22464-22479 Billing TOU Maximum Demand Register #8
+0,1 0x5380
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
+2,3 0x5381
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
+14,15 0x5387
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
