Address Point ID Description Options/Range Units Type R/W Notes
52768-52777 Waveform Log #1 Setup
52778-52787 Waveform Log #2 Setup
52788-52857 Reserved
52858-52867 PQ Log Setup
52868-53877 Reserved
Waveform Recorder Setup
53878-53949
+0 Sampling rate, samples per cycle 32, 64, 128 UINT16 R/W
+1 Maximum number of cycles per event series 16-2560 (32 samples/cycle),
8-1280 (64 samples/cycle),
4-640 (128 samples/cycle)
UINT16 R/W
+3 Recording time mode and number of post-event
cycles in event-controlled mode
Bit 15 – mode: 0=fixed time, 1=
event-controlled time
Bits 0-9 – post-event cycles: 0-2048
UINT16 R/W Event-controlled mode - V24.3.1
and higher
+4 Number of pre-event cycles 1-20 UINT16 R/W
+4,5 File channel mask, bitmap F9, 0x00000033 UINT32 R/W
+6,7 Not used 0 UINT32 R/W
53878-53885 Waveform Log #1 Setup
53886-53893 Waveform Log #2 Setup
Data Log Setup
54006-55541
+0 Data log parameter #1 ID 0x0000-0xFFFF UINT16 R/W
+1 Data log parameter #2 ID 0x0000-0xFFFF UINT16 R/W
+2 Data log parameter #3 ID 0x0000-0xFFFF UINT16 R/W
+3 Data log parameter #4 ID 0x0000-0xFFFF UINT16 R/W
+4 Data log parameter #5 ID 0x0000-0xFFFF UINT16 R/W
+5 Data log parameter #6 ID 0x0000-0xFFFF UINT16 R/W
+6 Data log parameter #7 ID 0x0000-0xFFFF UINT16 R/W
+7 Data log parameter #8 ID 0x0000-0xFFFF UINT16 R/W
+8 Data log parameter #9 ID 0x0000-0xFFFF UINT16 R/W
+9 Data log parameter #10 ID 0x0000-0xFFFF UINT16 R/W
+10 Data log parameter #11 ID 0x0000-0xFFFF UINT16 R/W
+11 Data log parameter #12 ID 0x0000-0xFFFF UINT16 R/W
+12 Data log parameter #13 ID 0x0000-0xFFFF UINT16 R/W
+13 Data log parameter #14 ID 0x0000-0xFFFF UINT16 R/W
+14 Data log parameter #15 ID 0x0000-0xFFFF UINT16 R/W
+15 Data log parameter #16 ID 0x0000-0xFFFF UINT16 R/W
+16-31 Reserved UINT16 R/W
54006-54037 Data log #1 Setup
54038-54069 Data log #2 Setup
54070-54101 Data log #3 Setup
54102-54133 Data log #4 Setup
54134-54165 Data log #5 Setup
