Satec PM174 User Manual

89
Format Code Value Description Notes
1-Sec Total Values
0x1406 High total kW import
0x1407 High total kW export
0x1408 High total kvar import
0x1409 High total kvar export
0x1402 High total kVA
0x9404 Low total PF Lag
0x9405 Low total PF Lead
1-Sec Auxiliary Values
0x1501 High neutral current
0x1502 High frequency
0x9502 Low frequency
0x1503 High voltage unbalance
1
0x1504 High current unbalance
Present Demands
0x1600 High V1/V12 Volt demand
1
0x1601 High V2/V23 Volt demand
1
0x1602 High V3/V31 Volt demand
1
0x1603 High I1 Ampere demand
0x1604 High I2 Ampere demand
0x1605 High I3 Ampere demand
0x1606 High block kW import demand
0x1607 High block kvar import demand
0x1608 High block kVA demand
0x1609 High sliding window kW import demand
0x160A High sliding window kvar import demand
0x160B High sliding window kVA demand
0x160F High accumulated kW import demand
0x1610 High accumulated kvar import demand
0x1611 High accumulated kVA demand
0x1612 High predicted kW import demand
0x1613 High predicted kvar import demand
0x1614 High predicted kVA demand
0x1616 High block kW export demand
0x1617 High block kvar export demand
0x1618 High sliding window kW export demand
0x1619 High sliding window kvar export demand
0x161A High accumulated kW export demand
0x161B High accumulated kvar export demand
0x161C High predicted kW export demand
0x161D High predicted kvar export demand
Setpoint Action ID
Action type Target
0x00 0x00 No action
0x20 0x00 Set Event flag #1
0x20 0x01 Set Event flag #2
0x20 0x02 Set Event flag #3
0x20 0x03 Set Event flag #4
0x21 0x00 Clear Event flag #1
0x21 0x01 Clear Event flag #2
0x21 0x02 Clear Event flag #3
0x21 0x03 Clear Event flag #4
0x30 0x00 Operate Relay #1
0x30 0x01 Operate Relay #2
0x30 0x02 Operate Relay #3
0x30 0x03 Operate Relay #4
0x31 0x00 Release latched Relay #1
0x31 0x01 Release latched Relay #2
0x31 0x02 Release latched Relay #3
0x31 0x03 Release latched Relay #4
0x40 0x00 Increment counter #1
0x40 0x01 Increment counter #2
0x40 0x02 Increment counter #3
0x40 0x03 Increment counter #4
0x41 0x00 Clear counter #1
0x41 0x01 Clear counter #2
F14
0x41 0x02 Clear counter #3
