Satec PM174 User Manual

87
Format Code Value Description Notes
Billing/TOU Energy Register Source ID
0x0000 None
0x0700-0x0703 Pulse input DI1-DI4
0x1700
kWh import
0x1701 kWh export
0x1704 kvarh import
0x1705 kvarh export
F11
0x1708 kVAh total
Setpoint Trigger Parameters ID
0x0000 None (condition is not active)
Setpoint Status
0x0080 Setpoint #1 ON
0x0081 Setpoint #2 ON
0x0082 Setpoint #3 ON
0x0083 Setpoint #4 ON
0x0084 Setpoint #5 ON
0x0085 Setpoint #6 ON
0x0086 Setpoint #7 ON
0x0087 Setpoint #8 ON
0x0088 Setpoint #9 ON
0x0089 Setpoint #10 ON
0x008A Setpoint #11 ON
0x008B Setpoint #12 ON
0x008C Setpoint #13 ON
0x008D Setpoint #14 ON
0x008E Setpoint #15 ON
0x008F Setpoint #16 ON
Event Flags
0x0300 Event flag #1 ON
0x0301 Event flag #2 ON
0x0302 Event flag #3 ON
0x0303 Event flag #4 ON
0x0304 Event flag #5 ON
0x0305 Event flag #6 ON
0x0306 Event flag #7 ON
0x0307 Event flag #8 ON
0x8300 Event flag #1 OFF
0x8301 Event flag #2 OFF
0x8302 Event flag #3 OFF
0x8303 Event flag #4 OFF
0x8304 Event flag #5 OFF
0x8305 Event flag #6 OFF
0x8306 Event flag #7 OFF
0x8307 Event flag #8 OFF
Internal Events
0x0400 kWh import pulse
0x0401 kWh export pulse
0x0403 kvarh import pulse
0x0404 kvarh export pulse
0x0405 kvarh total pulse
0x0406 kVAh total pulse
0x0407 Start new demand interval
0x0408 Start new tariff interval
0x0409 Start new volt/ampere demand interval
0x040A Start new sliding window demand interval
Timers
0x0500 Timer #1
0x0501 Timer #2
Status Inputs
0x0600 Status input #1 ON
0x0601 Status input #2 ON
0x0602 Status input #3 ON
0x0603 Status input #4 ON
0x8600 Status input #1 OFF
0x8601 Status input #2 OFF
F12
0x8602 Status input #3 OFF
