Satec PM174 User Manual

74
Address Point ID Description Options/Range Units Type R/W Notes
Analog Inputs Setup
62368-62379
+0 Input parameter ID 0 = input not assigned UINT16 R/W
+1 Not used 0 UINT16 R/W
+2,3 Zero scale value (0/4 mA) INT32 R/W
+4,5 Full scale value (20/1 mA) INT32 R/W
62368-62373 AI1 Setup
62374-62379 AI2 Setup
Analog Outputs Setup
62560-62571
+0 Output parameter ID F18 UINT16 R/W
+1 Not used 0 UINT16 R/W
+2,3 Zero scale value (0/4 mA) See Section 3.4 INT32 R/W
+4,5 Full scale value (20/1 mA) See Section 3.4 INT32 R/W
62560-62565 AO1 Setup
62566-62571 AO2 Setup
Analog Expander Setup
62752-62847 Analog expander outputs settings
will not be in effect until the analog
expander output is globally enabled
through the Device Options setup
+0 Output parameter ID F18 UINT16 R/W
+1 Not used 0 UINT16 R/W
+2,3 Zero scale value (0/4 mA) See Section 3.4 INT32 R/W
+4,5 Full scale value (20/1 mA) See Section 3.4 INT32 R/W
62752-62757 AX8 #1 Channel 1 Setup
62758-62763 AX8 #1 Channel 2 Setup
… …
62794-62799 AX8 #1 Channel 8 Setup
62800-62805 AX8 #2 Channel 1 Setup
62806-62811 AX8 #2 Channel 2 Setup
… …
62842-62847 AX8 #2 Channel 8 Setup
