Satec PM174 User Manual

66
Address Point ID Description Options/Range Units Type R/W Notes
EGD Producer Exchanges Setup
50454-50837
+0-1 Exchange consumer IP Address 0x01000000-0xFFFFFFFF UINT32 R/W Network byte order
+2 Production interval 1-60000
×10 ms
UINT16 R/W
+3 Exchange status 0=disabled, 1=enabled UINT16 R/W
+4,5 Reserved 0 UINT16 R/W
+6 Address range #1: Start point ID 0-65535, 0=end of the range list UINT16 R/W
+7 Address range #1: End point ID 1-65535 UINT16 R/W
+8 Address range #1: Data type 0=Word, 1=DWord, 2= Float UINT16 R/W
+9 Address range #2: Start point ID 0-65535, 0=end of the range list UINT16 R/W
+10 Address range #2: End point ID 1-65535 UINT16 R/W
+11 Address range #2: Data type 0=Word, 1=DWord, 2= Float UINT16 R/W
… R/W
+93 Address range #30: Start point ID 0-65535, 0=end of the range list UINT16 R/W
+94 Address range #30: End point ID 1-65535 UINT16 R/W
+95 Address range #30: Data type 0=Word, 1=DWord, 2= Float UINT16 R/W
50454-50549 Exchange #1
50550-50645 Exchange #2
50646-50741 Exchange #3
50742-50837 Exchange #4
DNP Options Setup
51158-51183
+0 Default Binary Input Static object variation F24 (default 0) UINT16 R/W
+1 Default Binary Input Change object variation F24 (default 1) UINT16 R/W
+2 Default Binary Counter object variation F24 (default 3) UINT16 R/W
+3 Default Frozen Binary Counter object variation F24 (default 4) UINT16 R/W
+4 Reserved UINT16 R/W
+5 Default Binary Counter Change Event object variation F24 (default 2) UINT16 R/W
+6 Default Analog Input object variation F24 (default 3) UINT16 R/W
+7 Reserved UINT16 R/W
+8 Reserved UINT16 R/W
+9 Default Analog Input Change Event object variation F24 (default 2) UINT16 R/W
+10 Re-mapping static point indices for event objects 0=disabled (default), 1=enabled UINT16 R/W
+11 16-bit BC Scaling
0=
×1 (default), 1=×10, 2=×100,
3=
×1000
UINT16 R/W
+12 16-bit AI Scaling 0=disabled, 1=enabled (default) UINT16 R/W
+13 Number of points allocated for Analog Input change
events
0 to 64 (default 32) UINT16 R/W
+14 Number of points allocated for Binary Input change
events
0 to 32 (default 0) UINT16 R/W
+15 Number of points allocated for Binary Counter change
events
0 to 64 (default 0) UINT16 R/W
+16 Select/Operate Timeout 2 to 30 seconds (default 10 sec) UINT16 R/W
