Format Code Value Description Notes
0x41 0x03 Clear counter #4
0x64 0x00 Clear all counters
0x51 0x00 Send event notification
0x60 0x00 Reset total energy
0x61 0x00 Reset all total maximum demands
0x61 0x01 Reset power maximum demands
0x61 0x02 Reset volt/ampere/harmonic maximum demands
0x62 0x00 Reset TOU energy
0x63 0x00 Reset TOU maximum demands
0x65 0x00 Clear Min/Max registers
0x70 0x00 Event log
0x71 0x00 Data log #1
0x71 0x01 Data log #2
0x71 0x02 Data log #3
0x71 0x03 Data log #4
0x71 0x04 Data log #5
0x71 0x05 Data log #6
0x71 0x06 Data log #7
0x71 0x07 Data log #8
0x71 0x0A Data log #11
0x71 0x0B Data log #12
0x71 0x0C Data log #13
0x71 0x0D Data log #14
0x71 0x0E Data log #15
0x71 0x0F Data log #16
0x72 0x00 Waveform log #1
0x73 0x00 Waveform log #2
Counter Source ID
0x0000 None F16
0x0001-0x0004 Pulse input DI1-DI4
Relay Output Pulse Source ID
0x0000 None
0x0400 kWh import pulse
0x0401 kWh export pulse
0x0403 kvarh import pulse
0x0404 kvarh export pulse
0x0405 kvarh total pulse
F17
0x0406 kVAh pulse
AO Output Parameters ID
0x0000 None (output disabled) Note 2
1-Cycle Phase Values
0x0C00 V1/V12 Voltage
1
0x0C01 V2/V23 Voltage
1
0x0C02 V3/V31 Voltage
1
0x0C03 I1 Current
0x0C04 I2 Current
0x0C05 I3 Current
0x0C1E V12 Voltage
0x0C1F V23 Voltage
0x0C20 V31 Voltage
1-Cycle Total Values
0x0F00 Total kW
0x0F01 Total kvar
0x0F02 Total kVA
0x0F03 Total PF
0x0F04 Total PF Lag
0x0F05 Total PF Lead
0x0F0A 3-phase average L-N/L-L voltage
1
0x0F0B 3-phase average L-L voltage
0x0F0C 3-phase average current
1-Cycle Auxiliary Values
0x1001 In Current
0x1002 Frequency
1-Sec Phase Values
0x1100 V1/V12 Voltage
0x1101 V2/V23 Voltage
F18
0x1102 V3/V31 Voltage
