Satec PM174 - I3 Harmonic Distortion; Fundamental Phase Values; Flicker; Fundamental Total Values

42
Address Point ID Description
Options/Range
3
Units
3
Type R/W Notes
15488-15587 I2 Harmonic Distortion
+0,1 0x1D00
H01 Harmonic distortion
0-10000 0.01% UINT32 R
+2,3 0x1D01
H02 Harmonic distortion
0-10000 0.01% UINT32 R
...
+98,99 0x1D31
H50 Harmonic distortion
0-10000 0.01% UINT32 R
15616-15715 I3 Harmonic Distortion
+0,1 0x1E00
H01 Harmonic distortion
0-10000 0.01% UINT32 R
+2,3 0x1E01
H02 Harmonic distortion
0-10000 0.01% UINT32 R
...
+98,99 0x1E31
H50 Harmonic distortion
0-10000 0.01% UINT32 R
17024-17059 Fundamental Phase Values
5
+0,1 0x2900 V1/V12 Voltage 0-Vmax U1 UINT32 R
2
+2,3 0x2901 V2/V23 Voltage 0-Vmax U1 UINT32 R
2
+4,5 0x2902 V3/V31 Voltage 0-Vmax U1 UINT32 R
2
+6,7 0x2903 I1 Current 0-Imax U2 UINT32 R
+8,9 0x2904 I2 Current 0-Imax U2 UINT32 R
+10,11 0x2905 I3 Current 0-Imax U2 UINT32 R
+12,13 0x2906 kW L1 -Pmax-Pmax U3 INT32 R
+14,15 0x2907 kW L2 -Pmax-Pmax U3 INT32 R
+16,17 0x2908 kW L3 -Pmax-Pmax U3 INT32 R
+18,19 0x2909 kvar L1 -Pmax-Pmax U3 INT32 R
+20,21 0x290A kvar L2 -Pmax-Pmax U3 INT32 R
+22,23 0x290B kvar L3 -Pmax-Pmax U3 INT32 R
+24,25 0x290C kVA L1 0-Pmax U3 UINT32 R
+26,27 0x290D kVA L2 0-Pmax U3 UINT32 R
+28,29 0x290E kVA L3 0-Pmax U3 UINT32 R
+30,31 0x290F Power factor L1 -1.000-1.000
×0.001
INT32 R
+32,33 0x2910 Power factor L2 -1.000-1.000
×0.001
INT32 R
+34,35 0x2911 Power factor L3 -1.000-1.000
×0.001
INT32 R
17088-17099 Flicker
2
+0,1 0x2980 V1 Pst 0-10000
×0.01
UINT32 R
+2,3 0x2981 V2 Pst 0-10000
×0.01
UINT32 R
+4,5 0x2982 V3 Pst 0-10000
×0.01
UINT32 R
+6,7 0x2983 V1 Plt 0-10000
×0.01
UINT32 R
+8,9 0x2984 V2 Plt 0-10000
×0.01
UINT32 R
+10,11 0x2985 V3 Plt 0-10000
×0.01
UINT32 R
17152-17159 Fundamental Total Values
5
+0,1 0x2A00 Total fundamental kW -Pmax-Pmax U3 INT32 R
+2,3 0x2A01 Total fundamental kvar -Pmax-Pmax U3 INT32 R
+4,5 0x2A02 Total fundamental kVA 0-Pmax U3 UINT32 R
+6,7 0x2A03 Total fundamental PF -1.000-1.000
×0.001
INT32 R
