Format Code Value Description Notes
0x0102 Binary Input 01:02
0x1401 Binary Counter 20:01
0x1402 Binary Counter 20:02
0x1405 Binary Counter 20:05
0x1406 Binary Counter 20:06
0x1501 Frozen Counter 21:01
0x1502 Frozen Counter 21:02
0x1505 Frozen Counter 21:05
0x1506 Frozen Counter 21:06
0x1509 Frozen Counter 21:09
0x150A Frozen Counter 21:10
Wiring Mode
0 3OP2 - 3-wire open delta using 2 CTs (2 element)
1 4LN3 - 4-wire WYE using 3 PTs (3 element), line-to-
neutral voltage readings
2 3DIR2 - 3-wire direct connection using 2 CTs (2 element)
3 4LL3 - 4-wire WYE using 3 PTs (3 element), line-to-line
voltage readings
4 3OP3 - 3-wire open delta using 3 CTs (2 1/2 element)
5 3LN3 - 4-wire WYE using 2 PTs (2 1/2 element), line-to-
neutral voltage readings
6 3LL3 - 4-wire WYE using 2 PTs (2 1/2 element), line-to-
line voltage readings
8 3BLN3 - 3-wire broken delta using 2 PTs (2 1/2 element),
line-to-neutral voltage readings
F26
9 3BLL3 - 3-wire broken delta using 2 PTs (2 1/2 element),
line-to-line voltage readings
Instrument Options
Bit 0=1 120V Option
Bit 1=1 690V Option
Bits 2-5 Reserved
Bit 6=1 Analog output 0/4 or 4/20mA
Bit 7=1 Analog output 0-1mA
Bit 8=1 Analog output ±1mA
Bit 9=1 RO option
Bit 10=1 DI option
Bit 11 Reserved
Bit 12=1 Setup is secured by a password (authorization required)
Bit 13 Reserved
Bit 14=1 Analog expander option ±1mA
Bit 15 Reserved
Bits 16-18 Number of RO - 1
Bits 19-22 Number of DI – 1
Bits 23-24 Number of AO - 1
Bits 25-29 Reserved
F28
Bits 30-31=11 Memory module 1MBytes
I/O Slot Types
DI DRY 00000000B
× = Don’t care
RO 00100000B
AI ±1 mA 01010000B
AI 0-20 mA 01010001B
AI 4-20 mA 01010010B
AI 0-1 mA 01010011B
AO ±1 mA 01100000B
AO 0-20 mA 01100001B
AO 4-20 mA 01100010B
AO 0-1 mA 01100011B
F29
Empty slot
1111××××B
NOTES:
1
Voltage
When the 4LN3, 3LN3 or 3BLN3 wiring mode is selected, the voltages and voltage waveforms will be line-to-neutral; for any
other wiring mode, they will be line-to-line.
2
Analog Outputs
