3.8 Analog and Digital I/O Configuration
Address Point ID Description Options/Range Units Type R/W Notes
I/O Slots Configuration Info
63008-63055
+0 I/O type F29 UINT16 R
+1 Number of I/Os on the slot 0-4 UINT16 R
+2 First I/O number on the slot 0 UINT16 R
+3 Last I/O number on the slot 0-3 UINT16 R
63008-63011 DI Slot Configuration
63012-63015 RO Slot Configuration
63016-63019 AI/AO Slot Configuration
63020-63055 Reserved
I/O Type Info
63056-63119
+0 Number of I/O slots of this type 0-1 UINT16 R
+1 Total number of I/O's of this type 0-4 UINT16 R
+2 Number of I/O's in the slot 0-4 UINT16 R
+3 Not used 0 UINT16 R
63056-63059 DI Type Info
63060-63063 RO Type Info
63064-63067 AI Type Info
63068-63071 AO Type Info
63076-63119 Reserved
