Satec PM174 User Manual

65
Address Point ID Description Options/Range Units Type R/W Notes
Network Setup
46576-46703
+0,1 Device IP Address 0x01000000-0xFFFFFFFF UINT32 R/W Network byte order
+2,3 Network subnet mask 0x00000001-0xFFFFFFFF UINT32 R/W Network byte order
+4,5 Network default gateway 0x00000000-0xFFFFFFFF UINT32 R/W Network byte order
+6,7 Use DHCP 0 = NO, 1 = YES UINT32 R/W
+8,9 TCP service port 502 = Modbus/TCP,
20000 = DNP3.0/TCP
UINT32 R/W
+10-127 Reserved R/W
Password Setup
46704-46707
+0,1 Communications password (4 digits) 0-9999 UINT32 R/W Read as 0
+2 Password protection enabled 0 = disabled, 1 = enabled UINT16 R/W
+3 Reserved UINT16 R/W
Expert Power Service Setup
46768-46783
+0,1 Expert Power server IP Address 0x01000000-0xFFFFFFFF UINT32 R/W Default = 207.232.60.18
+2,3 Expert Power server TCP service port 0-65535 UINT32 R/W Default = 5001
+4,5 Expert Power client enabled 0 = client disabled, 1 = client
enabled
UINT32 R/W
+6,7 Time to next session 1-99999 min UINT32 R/W
+8,9 Not used UINT32 R
+10,11 Not used UINT32 R
+12,13 Connection idle timeout 1-120 min UINT32 R/W
+14-15 Reserved UINT32
Internet Service Provider (ISP) accounts
46784-46831
+0-15 ISP telephone number CHAR32 R/W
+16-31 Login name CHAR32 R/W
+32-47 Login password CHAR32 R/W
GPRS Setup
46832-46879
+0-15 Access Point Name (APN) CHAR32 R/W
+16-31 User name CHAR32 R/W
+32-39 Password CHAR16 R/W
+40-47 Reserved CHAR16 R/W
TCP Notification Client Setup
46896-46991
+0,1 Client enabled 0 = disabled, 1 = enabled UINT32 R/W
+2,3 Server address 0x01000000-0xFFFFFFFF UINT32 R/W
+4,5 Server port 0-65535 UINT32 R/W
+6,7 Message exchange address 0-65535 UINT32 R/W
+8-15 Reserved
