Format Code Value Description Notes
0x1103 I1 Current
0x1104 I2 Current
0x1105 I3 Current
0x111E V12 Voltage
0x111F V23 Voltage
0x1120 V31 Voltage
1-Sec Total Values
0x1400 Total kW
0x1401 Total kvar
0x1402 Total kVA
0x1403 Total PF
0x1404 Total PF Lag
0x1405 Total PF Lead
0x140A 3-phase average L-N/L-L voltage
1
0x140B 3-phase average L-L voltage
0x140C 3-phase average current
1-Sec Auxiliary Values
0x1501 In Current
0x1502 Frequency
Present Demands
0x160F Accumulated kW import demand
0x1610 Accumulated kvar import demand
0x1611 Accumulated kVA demand
0x161A Accumulated kW export demand
0x161B Accumulated kvar export demand
Event Cause/Point ID
Setpoint Operation Events
0x0000-0x59FF Trigger parameter ID
0x6400-0xFFFF Trigger parameter ID
Setpoint Action Events
0x5A00-0x5A0F Setpoint #1-#16
Communications Events
0x5B00-0x5BFF Data point ID (low byte, see F21)
Front Panel Operations
0x5C00-0x5CFF Data point ID (low byte, see F21)
Self-Check Diagnostics Events
0x5D00-0x5DFF Data point ID (low byte, see F21)
Self-Update Events
0x5E08 RTC DST/Standard time update
Hardware Diagnostics Events
0x6202 RAM/Data error
0x6203 Hardware watchdog reset
0x6204 Sampling fault
0x6205 CPU exception
0x6206 Reserved
0x6207 Software watchdog reset
0x620D Low battery
0x620F EEPROM fault
External Events
0x6300 Power down
0x6308 Power up
F19
0x6309 External reset
Event Effect ID
Communications/Self-check/Front Panel Events
0x0000 None
0x6000 Total energy registers cleared
0x6100 All total maximum demands cleared
0x6101 Power maximum demands cleared
0x6102 Volt/Ampere/Harmonic maximum demands cleared
0x6200 Billing/TOU energy registers cleared
0x6300 Billing/TOU maximum demand registers cleared
0x6400 All counters cleared
0x6401-0x6403 Counter cleared (low byte = counter ID)
0x6500 Min/Max log cleared
0x6A00-0x6A1A Log file cleared (low byte = File ID)
0xF100-0xF10F Setpoint cleared (low byte = setpoint ID)
F20
0xF200 Setup/Data cleared
