Satec PM174 User Manual

43
Address Point ID Description
Options/Range
3
Units
3
Type R/W Notes
17408-17467 Minimum 1-Cycle Phase Values
+0,1 0x2C00 V1/V12 Voltage 0-Vmax U1 UINT32 R
2
+2,3 0x2C01 V2/V23 Voltage 0-Vmax U1 UINT32 R
2
+4,5 0x2C02 V3/V31 Voltage 0-Vmax U1 UINT32 R
2
+6,7 0x2C03 I1 Current 0-Imax U2 UINT32 R
+8,9 0x2C04 I2 Current 0-Imax U2 UINT32 R
+10,11 0x2C05 I3 Current 0-Imax U2 UINT32 R
+12-35 0x2C06-
0x2C11
Not used 0 INT32 R
+36,37 0x2C12 V1/V12 Voltage THD 0-9999
×0.1%
UINT32 R
2, 5
+38,39 0x2C13 V2/V23 Voltage THD 0-9999
×0.1%
UINT32 R
2, 5
+40,41 0x2C14 V3/V31 Voltage THD 0-9999
×0.1%
UINT32 R
2, 5
+42,43 0x2C15 I1 Current THD 0-9999
×0.1%
UINT32 R
5
+44,45 0x2C16 I2 Current THD 0-9999
×0.1%
UINT32 R
5
+46,47 0x2C17 I3 Current THD 0-9999
×0.1%
UINT32 R
5
+48,49 0x2C18 I1 K-Factor 10-9999
×0.1
UINT32 R
5
+50,51 0x2C19 I2 K-Factor 10-9999
×0.1
UINT32 R
5
+52,53 0x2C1A I3 K-Factor 10-9999
×0.1
UINT32 R
5
+54,55 0x2C1B I1 Current TDD 0-1000
×0.1%
UINT32 R
5
+56,57 0x2C1C I2 Current TDD 0-1000
×0.1%
UINT32 R
5
+58,59 0x2C1D I3 Current TDD 0-1000
×0.1%
UINT32 R
5
17536-17543 Minimum 1-Cycle Total Values
+0,1 0x2D00 Total kW -Pmax-Pmax U3 INT32 R
+2,3 0x2D01 Total kvar -Pmax-Pmax U3 INT32 R
+4,5 0x2D02 Total kVA 0-Pmax U3 UINT32 R
+6,7 0x2D03 Total PF 0-1000
×0.001
UINT32 R Absolute value
17664-17669 Minimum 1-Cycle Auxiliary Values
+0,1 0x2E00 Not used UINT32 R
+2,3 0x2E01 In Current 0-Imax U2 UINT32 R
+4,5 0x2E02 Frequency 0-Fmax
×0.01Hz
UINT32 R
18432-18491 Maximum 1-Cycle Phase Values
+0,1 0x3400 V1/V12 Voltage 0-Vmax U1 UINT32 R
2
+2,3 0x3401 V2/V23 Voltage 0-Vmax U1 UINT32 R
2
+4,5 0x3402 V3/V31 Voltage 0-Vmax U1 UINT32 R
2
+6,7 0x3403 I1 Current 0-Imax U2 UINT32 R
+8,9 0x3404 I2 Current 0-Imax U2 UINT32 R
+10,11 0x3405 I3 Current 0-Imax U2 UINT32 R
+12-35 0x3406-
0x3411
Not used 0 INT32 R
+36,37 0x3412 V1/V12 Voltage THD 0-9999
×0.1%
UINT32 R
2, 5
+38,39 0x3413 V2/V23 Voltage THD 0-9999
×0.1%
UINT32 R
2, 5
+40,41 0x3414 V3/V31 Voltage THD 0-9999
×0.1%
UINT32 R
2, 5
+42,43 0x3415 I1 Current THD 0-9999
×0.1%
UINT32 R
5
