Satec PM174 User Manual

72
Address Point ID Description Options/Range Units Type R/W Notes
8-11 = Season 3, Day types 0-3
12-15 = Season 4, Day types 0-3
+1 Week of month 0=all, 1=1st, 2=2nd, 3=3
rd
, 4=4th,
5=last week of the month
UINT16 R/W
+2 Weekday 0=all, 1-7 (Sun=1, Sat=7) UINT16 R/W
+3 Till Weekday 0=all, 1-7 (Sun=1, Sat=7) UINT16 R/W
+4 Month 0=all, 1-12=January - December UINT16 R/W
+5 Day of month 0=all, 1-31=day 1-31 UINT16 R/W
+6 Till Month 0=all, 1-12=January - December UINT16 R/W
+7 Till Day of month 0=all, 1-31=day 1-31 UINT16 R/W
+8-9 Reserved UINT16 R/W
55712-55721 Calendar entry #1
55722-55731 Calendar entry #2
55732-55741 Calendar entry #3
…
56022-56031 Calendar entry #32
56032-56191 Reserved
Billing/TOU Registers Setup
56672-56703
+0 Not used UINT16 R/W
+1 Units of measurement 0=none, 1=kWh, 2=kvarh, 3=kVAh,
4=m
3
, 5=CF (cubic feet), 6=CCF
(hundred cubic feet)
UINT16 R/W
+2 Flags (bitmap) Bit 0=1 - TOU enabled
Bit 1=1 - Use profile enabled
Bit 2=1 - Max. Demand profile
enabled
Bit 3=1 - Summary (total) profile
enabled
UINT16 R/W
+3 Not used 0 UINT16 R/W
56672-56675 Register #1 Setup
56676-56679 Register #2 Setup
56680-56683 Register #3 Setup
56684-56687 Register #4 Setup
56688-56691 Register #5 Setup
56692-56695 Register #6 Setup
56696-56699 Register #7 Setup
56700-56703 Register #8 Setup
Billing/TOU Registers Source Setup
56928-57183
+0 Energy source ID F11 UINT16 R/W
+1 Target billing register number 0-7 = register #1-#8 UINT16 R/W
+2,3 Multiplier 0-1000000
×0.001
INT32 R/W
