Satec PM174 User Manual

73
Address Point ID Description Options/Range Units Type R/W Notes
56928-56931 Energy Source #1
56932-56935 Energy Source #2
56936-56939 Energy Source #3
56940-56943 Energy Source #4
56944-56947 Energy Source #5
56948-56951 Energy Source #6
56952-56955 Energy Source #7
56956-56959 Energy Source #8
Periodic Timers Setup
61024-61031
+0, 1 Time interval, in seconds 0=timer disabled, 1,000-9999,000
ms (1-9999 sec)
0.001 s UINT32 R/W
61024-61025 Timer #1 Setup 0.001 s UINT32 R/W
61026-61027 Timer #2 Setup 0.001 s UINT32 R/W
61028-61029 Timer #3 Setup 0.001 s UINT32 R/W
61030-61031 Timer #4 Setup 0.001 s UINT32 R/W
Digital Inputs Setup
61728-61743
+0 Pulse mode 0 = pulse, 1 = KYZ UINT16 R/W
+1 Polarity 0 = normal, 1 = inverting UINT16 R/W
+2 De-bounce time, ms 1-1000 UINT16 R/W Debounce time will be the same for
both inputs
+3 Reserved UINT16 R/W
61728-61731 DI1 Setup
61732-61735 DI2 Setup
61736-61739 DI3 Setup
61740-61743 DI4 Setup
Relay Outputs Setup
61984-62007
+0 Operation Mode 0=latched, 1=unlatched,
2=pulse, 3=KYZ
UINT16 R/W
+1 Polarity Bit 0 – Polarity:
0=normal, 1=inverting,
Bit 1 - Retentive mode:
0=disabled, 1=enabled
UINT16 R/W
+2 Pulse width, ms 1-1000 UINT16 R/W
+3 Pulse source ID F17 UINT16 R/W
+4 Units per pulse 1-10000 x0.1 UINT16 R/W
+5 Reserved UINT16 R/W
61984-61989 RO1 Setup
61990-61995 RO2 Setup
61996-62001 RO3 Setup
62002-62007 RO4 Setup
