Address Point ID Description Options/Range Units Type R/W Notes
63160-… Record #1 (variable length)
...
Record #16 (variable length)
Waveform Log Response Block
63152-63159 Block Heading
+0 Last file function 1, 3, 5, 11 UINT16 R
+1 File ID 17-18, 128 (F2) UINT16 R
+2 Section number 0-9 UINT16 R
+3 Section channel ID F7 UINT16 R
+4 Number of records in the block 1 UINT16 R
+5 Record size, words 640 UINT16 R
+6 Request variation 0 UINT16 R
+7 Reserved 0 UINT16 R
63160-63799 Waveform Log Record
+0 Record status F5 INT16 R
+1 Record sequence number 0-65535 UINT16 R
+2, 3 Start time, seconds since 1/1/1970 F1 sec UINT32 R
+4, 5 Start time, fractional seconds µsec UINT32 R
+6, 7 Trigger time, seconds since 1/1/1970 F1 sec UINT32 R
+8, 9 Trigger time, fractional seconds µsec UINT32 R
+10 Record series number 1-65535 UINT16 R
+11 Record serial number in a series 0-65535 UINT16 R
+12 Trigger event type F22 UINT16 R
+13 Trigger event number 1-65535 UINT16 R
+14 Source point ID (generic) See Generic Data in Section 3.4 UINT16 R
+15 Trigger reference sample index 0–511 UINT16 R
+16 Sampling rate, µsec/sample 600-27000
×0.1µsec
UINT16 R
+17 Sampling rate, samples/cycle 32, 64, 128 UINT16 R
+18 Sampling frequency 4500 – 6500
×0.01Hz
UINT16 R
+19 Channel offset, sampling units 0 INT16 R
+20, 21 Channel multiplier, primary units See Generic Data in Section 3.4 UINT32 R
+22 Channel divisor, sampling units 32767 UINT16 R
+23 Length of a sample series, data points 512 UINT16 R
+24-127 Not used 0 UINT16 R
+128 Sample Series
+128-639 Sample data series points [0...511] -32768 - 32767 INT16 R
1
Power Quality (PQ) Log Response Block
63152-63159 Block Heading
+0 Last file function 1, 3, 5, 11 UINT16 R
+1 File ID 26 UINT16 R
+2 Section number 0 UINT16 R
+3 Section channel ID 0 UINT16 R
+4 Number of records in the block 1-16 UINT16 R
