Satec PM174 User Manual

27
Address Point ID Description
Low and High Scales
3
Units
3
Type R/W Notes
+10,11 0x1805 kvarh import L3 0-999,999,999 1 kvarh UINT32 R
+12,13 0x1806 kVAh total L1 0-999,999,999 1 kVAh UINT32 R
+14,15 0x1807 kVAh total L2 0-999,999,999 1 kVAh UINT32 R
+16,17 0x1808 kVAh total L3 0-999,999,999 1 kVAh UINT32 R
5152-5161 Symmetrical Components
+0 0x1880 Positive-sequence voltage 0-Vmax U1 UINT16 R
+1 0x1881 Negative-sequence voltage 0-Vmax U1 UINT16 R
+2 0x1882 Zero-sequence voltage 0-Vmax U1 UINT16 R
+3 0x1883 Negative-sequence voltage unbalance 0-300.0 0.1% UINT16 R
+4 0x1884 Zero-sequence voltage unbalance 0-300.0 0.1% UINT16 R
+5 0x1885 Positive-sequence current 0-Imax U2 UINT16 R
+6 0x1886 Negative-sequence current 0-Imax U2 UINT16 R
+7 0x1887 Zero-sequence current 0-Imax U2 UINT16 R
+8 0x1888 Negative-sequence current unbalance 0-300.0 0.1% UINT16 R
+9 0x1889 Zero-sequence current unbalance 0-300.0 0.1% UINT16 R
5184-5233 V1/V12 Harmonic Distortion
2
+0 0x1900
H01 Harmonic distortion
0-100.00 0.01% UINT16 R
+1 0x1901
H02 Harmonic distortion
0-100.00 0.01% UINT16 R
...
+49 0x1931
H50 Harmonic distortion
0-100.00 0.01% UINT16 R
5248-5297 V2/V23 Harmonic Distortion
2
+0 0x1A00
H01 Harmonic distortion
0-100.00 0.01% UINT16 R
+1 0x1A01
H02 Harmonic distortion
0-100.00 0.01% UINT16 R
...
+49 0x1A31
H50 Harmonic distortion
0-100.00 0.01% UINT16 R
5312-5361 V3/V31 Harmonic Distortion
2
+0 0x1B00
H01 Harmonic distortion
0-100.00 0.01% UINT16 R
+1 0x1B01
H02 Harmonic distortion
0-100.00 0.01% UINT16 R
...
+49 0x1B31
H50 Harmonic distortion
0-100.00 0.01% UINT16 R
5376-5425 I1 Harmonic Distortion
+0 0x1C00
H01 Harmonic distortion
0-100.00 0.01% UINT16 R
+1 0x1C01
H02 Harmonic distortion
0-100.00 0.01% UINT16 R
...
+49 0x1C31
H50 Harmonic distortion
0-100.00 0.01% UINT16 R
5440-5489 I2 Harmonic Distortion
+0 0x1D00
H01 Harmonic distortion
0-100.00 0.01% UINT16 R
+1 0x1D01
H02 Harmonic distortion
0-100.00 0.01% UINT16 R
...
+49 0x1D31
H50 Harmonic distortion
0-100.00 0.01% UINT16 R
