Address Point ID Description Options/Range Units Type R/W Notes
…
51795-51797 DNP Class 0 Points Range 32
51798-51893 Reserved
PQ Log Triggers Setup (IEEE 1159 disturbance categories)
52342-52597
+0 Threshold, % 0-2000 x 0.1% UINT16 R/W
+1 Hysteresis, % of threshold 0-500 x 0.1% UINT16 R/W
+2 Log options, bitmap Bit 0 – waveform log on event start:
0 = disabled, 1 = enabled;
Bit 1 – waveform log on event end:
0 = disabled, 1 = enabled.
UINT16 R/W
+3 Waveform log number 0-1 = log #1 - #2 UINT16 R/W
+4-15 Reserved 0 UINT16 R/W
52342-52357 Impulsive transients
52358-52373 Sag
52374-52389 Swell
52390-52405 Interruption
52406-52421 Voltage unbalance
52422-52437 Frequency variation
52438-52453 Harmonics
52454-52469 Inter-harmonics
52470-52485 Flicker
52486-52597 Reserved
Fault Log Triggers Setup
52150-52277 V24.3.1 and higher
+0 Trigger 1: Threshold, % 0 - 2000 x 0.1% UINT16 R/W
+1 Trigger 1: Hysteresis, % of threshold 0 - 500 x 0.1% UINT16 R/W
+2 Trigger 1: Trigger enabled 0 = disabled, 1 = enabled UINT16 R/W
+3 Trigger 2: Threshold, % 0 - 2000 x 0.1% UINT16 R/W
+4 Trigger 2: Hysteresis, % of threshold 0 - 500 x 0.1% UINT16 R/W
+5 Trigger 2: Trigger enabled 0 = disabled, 1 = enabled UINT16 R/W
+6-7 Not used UINT16 R/W
52150-52157 External trigger N/A
52158-52165 Zero-sequence current N/A
52166-52173 Zero-sequence voltage N/A
52174-52181 Current unbalance N/A
52182-52189 Voltage unbalance N/A
52190-52197 Overcurrent and Undervoltage
52198-52205 Undervoltage
52206-52213 I4 (neutral) current
52214-52277 Reserved UINT16 R/W
