93
Format Code Value Description Notes
0x0200 FE: Generic fault event
0x0201 FE1: Zero-sequence current
0x0202 FE2: Zero-sequence voltage
0x0203 FE3: Current unbalance
0x0204 FE4: Voltage unbalance
0x0205 FE5: Overcurrent
0x0206 FE6: Undervoltage
0x0207 FE7: Neutral current
Device Diagnostics
Bit 0 Reserved
Bit 1 Reserved
Bit 2 = 1 RAM/Data error
Bit 3 = 1 CPU watchdog reset
Bit 4 = 1 Sampling fault
Bit 5 = 1 CPU exception
Bit 6 Reserved
Bit 7 = 1 Software watchdog reset
Bit 8 = 1 Power down
Bit 9 = 1 Device reset
Bit 10 = 1 Configuration reset
Bit 11 = 1 RTC fault
Bit 12 Reserved
Bit 13 = 1 Low battery
Bit 14 Reserved
F23
Bit 15 = 1 EEPROM fault
DNP Object Types
Static Binary Input Objects
0 Single-Bit Binary Input
1 Binary Input With Status
Binary Input Change Event Objects
0 Binary Input Change Without Time
1 Binary Input Change With Time
Static Binary Counters
0 32-bit Binary Counter
1 32-bit Binary Counter Without Flag
2 16-bit Binary Counter
3 16-bit Binary Counter Without Flag
Binary Counter Change Events
0 32-bit Counter Change Event Without Time
1 32-bit Counter Change Event With Time
2 16-bit Counter Change Event Without Time
3 16-bit Counter Change Event With Time
Frozen Binary Counters
0 32-bit Frozen Counter
1 32-bit Frozen Counter Without Flag
2 32-bit Frozen Counter With Time of Freeze
3 16-bit Frozen Counter
4 16-bit Frozen Counter Without Flag
5 16-bit Frozen Counter With Time of Freeze
Static Analog Input Objects
0 32-bit Analog Input
1 32-bit Analog Input Without Flag
2 16-bit Analog Input
3 16-bit Analog Input Without Flag
Analog Input Change Events
0 32-bit Analog Change Event Without Time
1 32-bit Analog Change Event With Time
2 16-bit Analog Change Event Without Time
F24
3 16-bit Analog Change Event With Time
DNP Class 0 Objects
0x1E01 Analog Input 30:01
0x1E02 Analog Input 30:02
0x1E03 Analog Input 30:03
0x1E04 Analog Input 30:04
0x2801 Analog Output 40:01
0x2802 Analog Output 40:02
F25
0x0101 Binary Input 01:01
