Satec PM174 User Manual

20
3.2 16-bit Scaled Analog Registers and Energy Counters - Basic Register Set
Address Point ID Description
Low and High Scales
2
Units
2
Type R/W Notes
256-308
+0 0x1100 V1/V12 Voltage 0-Vmax U1 UINT16 R
1
+1 0x1101 V2/V23 Voltage 0-Vmax U1 UINT16 R
1
+2 0x1102 V3/V31 Voltage 0-Vmax U1 UINT16 R
1
+3 0x1103 I1 Current 0-Imax U2 UINT16 R
+4 0x1104 I2 Current 0-Imax U2 UINT16 R
+5 0x1105 I3 Current 0-Imax U2 UINT16 R
+6 0x1106 kW L1 -Pmax-Pmax U3 INT16 R
+7 0x1107 kW L2 -Pmax-Pmax U3 INT16 R
+8 0x1108 kW L3 -Pmax-Pmax U3 INT16 R
+9 0x1109 kvar L1 -Pmax-Pmax U3 INT16 R
+10 0x110A kvar L2 -Pmax-Pmax U3 INT16 R
+11 0x110B kvar L3 -Pmax-Pmax U3 INT16 R
+12 0x110C kVA L1 -Pmax-Pmax U3 UINT16 R
+13 0x110D kVA L2 -Pmax-Pmax U3 UINT16 R
+14 0x110E kVA L3 -Pmax-Pmax U3 UINT16 R
+15 0x110F Power factor L1 -1.000-1.000 0.001 INT16 R
+16 0x1110 Power factor L2 -1.000-1.000 0.001 INT16 R
+17 0x1111 Power factor L3 -1.000-1.000 0.001 INT16 R
+18 0x1403 Total PF -1.000-1.000 0.001 INT16 R
+19 0x1400 Total kW -Pmax-Pmax U3 INT16 R
+20 0x1401 Total kvar -Pmax-Pmax U3 INT16 R
+21 0x1402 Total kVA -Pmax-Pmax U3 UINT16 R
+22 0x1501 In (neutral) Current 0-Imax U2 UINT16 R
+23 0x1502 Frequency 45.00-65.00 0.01Hz UINT16 R
+24 0x3709 Maximum kW import sliding window demand -Pmax-Pmax U3 UINT16 R
+25 0x160F kW import accumulated demand -Pmax-Pmax U3 UINT16 R
+26 0x370B Maximum kVA sliding window demand -Pmax-Pmax U3 UINT16 R
+27 0x1611 kVA accumulated demand -Pmax-Pmax U3 UINT16 R
+28 0x3703 I1 Maximum ampere demand 0-Imax U2 UINT16 R
+29 0x3704 I2 Maximum ampere demand 0-Imax U2 UINT16 R
+30 0x3705 I3 Maximum ampere demand 0-Imax U2 UINT16 R
+31 kWh import (low) 0-9999 1kWh UINT16 R
6
+32 kWh import (high) 0-9999
×10MWh
UINT16 R
6
+33 kWh export (low) 0-9999 1kWh UINT16 R
6
+34 kWh export (high) 0-9999
×10MWh
UINT16 R
6
+35 +kvarh net (low) 0-9999 1kvarh UINT16 R
4, 6
+36 +kvarh net (high) 0-9999
×10Mvarh
UINT16 R
4, 6
+37 -kvarh net (low) 0-9999 1kvarh UINT16 R
5, 6
+38 -kvarh net (high) 0-9999
×10Mvarh
UINT16 R
5, 6
