22
3.3 16-bit Scaled Analog Registers, Binary Registers and Counters
Address Point ID Description
Low and High Scales
3
Units
3
Type R/W Notes
3584 0x0000 None 0 UINT16 R
3616 0x0080 Setpoint Status (bitmap) 0x0000-0xFFFF UINT16 R
3648-3649 Special Inputs
+0 0x0100 Reserved 0 UINT16 R
+1 0x0101 Phase rotation order 0=error, 1=positive (ABC),
2=negative (CBA)
UINT16 R
3776 0x0300 Event Flags (bitmap) 0x0000-0x00FF UINT16 R
3968 0x0600 Digital Inputs (bitmap) 0x0000-0x000F UINT16 R
4096 0x0800 Relay Outputs (bitmap) 0x0000-0x000F UINT16 R
4224-4231 Counters
+0,1 0x0A00 Counter #1 0-999,999 UINT32 R/W
+2,3 0x0A01 Counter #2 0-999,999 UINT32 R/W
+4,5 0x0A02 Counter #3 0-999,999 UINT32 R/W
+6,7 0x0A03 Counter #4 0-999,999 UINT32 R/W
4320-4331 1/2-Cycle Values
+0 0x0B80 V1 Voltage 0-Vmax U1 UINT16 R
1
+1 0x0B81 V2 Voltage 0-Vmax U1 UINT16 R
1
+2 0x0B82 V3 Voltage 0-Vmax U1 UINT16 R
1
+3 0x0B83 Reserved 0 UINT16 R
+4 0x0B84 V12 Voltage 0-Vmax U1 UINT16 R
+5 0x0B85 V23 Voltage 0-Vmax U1 UINT16 R
+5 0x0B86 V31 Voltage 0-Vmax U1 UINT16 R
+7 0x0B87 I1 Current 0-Imax U2 UINT16 R
+8 0x0B88 I2 Current 0-Imax U2 UINT16 R
+9 0x0B89 I3 Current 0-Imax U2 UINT16 R
+10 0x0B8A Reserved 0 UINT16 R
+11 0x0B8B In Current 0-Imax U2 UINT16 R
4352-4384 1-Cycle Phase Values
+0 0x0C00 V1/V12 Voltage 0-Vmax U1 UINT16 R
1
+1 0x0C01 V2/V23 Voltage 0-Vmax U1 UINT16 R
1
+2 0x0C02 V3/V31 Voltage 0-Vmax U1 UINT16 R
1
+3 0x0C03 I1 Current 0-Imax U2 UINT16 R
+4 0x0C04 I2 Current 0-Imax U2 UINT16 R
+5 0x0C05 I3 Current 0-Imax U2 UINT16 R
+6 0x0C06 kW L1 -Pmax-Pmax U3 INT16 R
+7 0x0C07 kW L2 -Pmax-Pmax U3 INT16 R
+8 0x0C08 kW L3 -Pmax-Pmax U3 INT16 R
+9 0x0C09 kvar L1 -Pmax-Pmax U3 INT16 R
+10 0x0C0A kvar L2 -Pmax-Pmax U3 INT16 R
+11 0x0C0B kvar L3 -Pmax-Pmax U3 INT16 R
