Address Point ID Description
Options/Range
3
Units
3
Type R/W Notes
+14,15 0x3887 Not used UINT32 R
+16,17 0x3888 I1 TDD demand 0-1000
×0.1%
UINT32 R
+18,19 0x3889 I2 TDD demand 0-1000
×0.1%
UINT32 R
+20,21 0x388A I3 TDD demand 0-1000
×0.1%
UINT32 R
+22,23 0x388B Not used UINT32 R
19328-19359 Scaled Analog Inputs
+0,1 0x3B00 Analog input AI1 AI1min-AI1Max UINT32 R
+2,3 0x3B01 Analog input AI2 AI2min-AI2Max UINT32 R
19392-19393 Raw Analog Inputs
+0,1 0x3B80 Analog input AI1 0-4095 UINT32 R
+2,3 0x3B81 Analog input AI2 0-4095 UINT32 R
19456-19459 TOU Parameters
+0,1 0x3C00 Active tariff 0-7 UINT32 R
+2,3 0x3C01 Active profile 0-15:
1-3 = Season 1 Profile #1-4,
4-7 = Season 2 Profile #1-4,
8-11 = Season 3 Profile #1-4,
12-15 = Season 4 Profile #1-4
UINT32 R
19520-19524 Scaled Analog Outputs
+0,1 0x3C80 Analog output AO1 0-4095 UINT32 R/W
+2,3 0x3C81 Analog output AO2 0-4095 UINT32 R/W
19584-19599 Billing TOU Energy Register #1
+0,1 0x3D00
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x3D01
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x3D07
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
19712-19727 Billing TOU Energy Register #2
+0,1 0x3E00
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x3E01
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x3E07
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
19840-19855 Billing TOU Energy Register #3
+0,1 0x3F00
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x3F01
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x3F07
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
19968-19983 Billing TOU Energy Register #4
+0,1 0x4000
Tariff #1 register
0-999,999,999 1 kWh UINT32 R
+2,3 0x4001
Tariff #2 register
0-999,999,999 1 kWh UINT32 R
… R
+14,15 0x4007
Tariff #8 register
0-999,999,999 1 kWh UINT32 R
