Satec PM174 User Manual

79
Address Point ID Description Options/Range Units Type R/W Notes
Event Log Response Block
63152-63159 Block Heading
+0 Last file function 1, 3, 5, 11 UINT16 R
+1 File ID 0 UINT16 R
+2 Section number 0 UINT16 R
+3 Section channel ID 0 UINT16 R
+4 Number of records in the block 1-32 UINT16 R
+5 Record size, words 12 UINT16 R
+6 Request variation 0 UINT16 R
+7 Reserved 0 UINT16 R
63160-63543 Event Log Records
+0 Record status F5 INT16 R
+1 Record sequence number 0-65535 UINT16 R
+2, 3 Trigger time, seconds since 1/1/1970 F1 sec UINT32 R
+4, 5 Trigger time, fractional seconds in µsec µsec UINT32 R
+6 Event number 1-65535 UINT16 R
+7 Event point/source ID F19 UINT16 R
+8 Event effect F20 UINT16 R
+9 Reserved 0 UINT16 R
+10, 11 Value triggered INT32 R
63160-63171 Record #1
...
63532-63543 Record #32
Data Log Response Block
63152-63159 Block Heading
+0 Last file function 1, 3, 5, 11 UINT16 R
+1 File ID 1-16 UINT16 R
+2 Section number 0-7 UINT16 R
+3 Section channel ID F6 UINT16 R
+4 Number of records in the block 1-16 UINT16 R
+5 Record size, words
8 + 2
× Number of parameters
UINT16 R
+6 Request variation 0 UINT16 R
+7 Reserved 0 UINT16 R
63160-64439 Data Log Records
+0 Record status F5 INT16 R
+1 Record sequence number 0-65535 UINT16 R
+2, 3 Record time, seconds since 1/1/1970 F1 sec UINT32 R
+4, 5 Record time, fractional seconds in µsec µsec UINT32 R
+6 Trigger event type F22 INT16 R
+7 Trigger event number 0 UINT16 R
+8, 9 Log value #1 INT32 R
+10, 11 Log value #2 INT32 R
… R
