58
Address Point ID Description Options/Range Units Type R/W Notes
44086-44101 Reserved UINT16
Reset/Clear Registers
44102 Clear Energies 0 UINT16 W
44103 Clear Maximum demands 0 = clear all maximum demands
1 = clear power demands
2 = clear volt, ampere and
harmonic demands
UINT16 W
44104 Clear Billing/TOU energy registers 0 UINT16 W
44105 Clear Billing/TOU maximum demands 0 UINT16 W
44106 Clear Counters 0 = clear all counters,
1-4 = clear counter #1-#4
UINT16 W
44107 Clear Min/Max log 0 UINT16 W
44108 Clear operation/event counters 6 = clear communication counters UINT16 W
44109-44133 Reserved UINT16
Device Mode Control Registers
44134-44135 Reserved UINT16
44136 PQ recorder 0 = disabled, 1 = enabled UINT16 R/W
44137 Fault recorder 0 = disabled, 1 = enabled UINT16 R/W
44138-44165 Reserved UINT16
Memory Status Registers
44262-44263 Memory size, bytes UINT32 R
44264-44265 Free memory, bytes UINT32 R
44266-44277 Reserved UINT32 R
Log Notification Registers (bit map)
44278-44279 Files 0-31 (0 = no new logs, 1 = new record logged) 0x00000000 - 0xFFFFFFFF UINT32 R
44280-44293 Reserved 0 UINT32 R
Setpoint Status Registers (bit map)
44294-44295 Setpoints 1-16 status (0 = released, 1 = operated) 0x00000000 - 0x0000FFFF UINT32 R
44296-44309 Reserved UINT32 R
Setpoint Alarm Latch Registers (bit map)
44310-44311 Setpoints 1-16 alarm status. When read: 0 = no
setpoint operations logged, 1 = setpoint has been
operated at least once since the last alarm bit reset.
When written: 0 = clear setpoint alarm bit, 1 = no
effect.
0x00000000 - 0x0000FFFF UINT32 R/W
44312-44325 Reserved
Device Diagnostics Register (bit map)
44326-44327 Device self-diagnostics flags.
When read: 0 = no faults logged, 1 = a fault bit has
been set at least once since the last reset.
When written: 0 = clear a fault bit, 1 = no effect.
F23 UINT32 R/W
44328-44341 Reserved
Current Port Number
44342 Active port number 0-1 = serial port COM1-COM2 UINT16 R
