Satec PM174 User Manual

62
Address Point ID Description Options/Range Units Type R/W Notes
+0 Power calculation mode 0=using reactive power: S=f(P,Q),
1=using non-active power:
Q=f(S,P)
UINT16 R/W
+1 Energy roll value
0=1
×10
4
, 1=1×10
5
, 2=1×10
6
,
3=1
×10
7
, 4=1×10
8
, 5=1x10
9
UINT16 R/W
+2 Phase energy calculation mode 0=disabled, 1=enabled UINT16 R/W
+3 Reserved UINT16 R/W Read as 65535
+4 Analog expander output option 0=none
1=0-20 mA
2=4-20 mA
3=0-1 mA
4=
±1 mA
UINT16 R/W
+5 Battery mode 0 = battery is OFF, 1 = battery is
ON
UINT16 R/W
+6-9 Reserved UINT16 R/W Read as 65535
+10 Energy LED test mode 0=disabled, 1=Wh test, 2=varh test UINT16 R/W LED pulse rate is 10,000
pulses/kWh
Alarm/Event Setpoints Setup
352-1055
+0 Condition #1: Logical operator 0 = OR, 1 = AND UINT16 R/W
+1 Condition #1: Trigger parameter ID F12 UINT16 R/W
+2 Condition #1: Reserved 0 UINT16 R/W
+3 Condition #1: Reserved 0 UINT16 R/W
+4,5 Condition #1: Operate limit See Section 3.3 UINT32 R/W Scaled value
+6,7 Condition #1: Release limit See Section 3.3 UINT32 R/W Scaled value
+8 Condition #2: Logical operator 0 = OR, 1 = AND UINT16 R/W
+9 Condition #2: Trigger parameter ID F12 UINT16 R/W
+10 Condition #2: Reserved 0 UINT16 R/W
+11 Condition #2: Reserved 0 UINT16 R/W
+12,13 Condition #2: Operate limit See Section 3.3 UINT32 R/W Scaled value
+14,15 Condition #2: Release limit See Section 3.3 UINT32 R/W Scaled value
+16 Condition #3: Logical operator 0 = OR, 1 = AND UINT16 R/W
+17 Condition #3: Trigger parameter ID F12 UINT16 R/W
+18 Condition #3: Reserved 0 UINT16 R/W
+19 Condition #3: Reserved 0 UINT16 R/W
+20,21 Condition #3: Operate limit See Section 3.3 UINT32 R/W Scaled value
+22,23 Condition #3: Release limit See Section 3.3 UINT32 R/W Scaled value
+24 Condition #4: Logical operator 0 = OR, 1 = AND UINT16 R/W
+25 Condition #4: Trigger parameter ID F12 UINT16 R/W
+26 Condition #4: Reserved 0 UINT16 R/W
+27 Condition #4: Reserved 0 UINT16 R/W
+28,29 Condition #4: Operate limit See Section 3.3 UINT32 R/W Scaled value
+30,31 Condition #4: Release limit See Section 3.3 UINT32 R/W Scaled value
