Satec PM174 User Manual

26
Address Point ID Description
Low and High Scales
3
Units
3
Type R/W Notes
+3 0x1603 I1 Ampere demand 0-Imax U2 UINT16 R
+4 0x1604 I2 Ampere demand 0-Imax U2 UINT16 R
+5 0x1605 I3 Ampere demand 0-Imax U2 UINT16 R
+6 0x1606 kW import block demand 0-Pmax U3 UINT16 R
+7 0x1607 kvar import block demand 0-Pmax U3 UINT16 R
+8 0x1608 kVA block demand 0-Pmax U3 UINT16 R
+9 0x1609 kW import sliding window demand 0-Pmax U3 UINT16 R
+10 0x160A kvar import sliding window demand 0-Pmax U3 UINT16 R
+11 0x160B kVA sliding window demand 0-Pmax U3 UINT16 R
+12 0x160C Not used UINT16 R
+13 0x160D Not used UINT16 R
+14 0x160E Not used UINT16 R
+15 0x160F kW import accumulated demand 0-Pmax U3 UINT16 R
+16 0x1610 kvar import accumulated demand 0-Pmax U3 UINT16 R
+17 0x1611 kVA accumulated demand 0-Pmax U3 UINT16 R
+18 0x1612 kW import predicted sliding window demand 0-Pmax U3 UINT16 R
+19 0x1613 kvar import predicted sliding window demand 0-Pmax U3 UINT16 R
+20 0x1614 kVA predicted sliding window demand 0-Pmax U3 UINT16 R
+21 0x1615 PF (import) at Max. kVA sliding window demand 0-1.000 0.001 UINT16 R
+22 0x1616 kW export block demand 0-Pmax U3 UINT16 R
+23 0x1617 kvar export block demand 0-Pmax U3 UINT16 R
+24 0x1618 kW export sliding window demand 0-Pmax U3 UINT16 R
+25 0x1619 kvar export sliding window demand 0-Pmax U3 UINT16 R
+26 0x161A kW export accumulated demand 0-Pmax U3 UINT16 R
+27 0x161B kvar export accumulated demand 0-Pmax U3 UINT16 R
+28 0x161C kW export predicted sliding window demand 0-Pmax U3 UINT16 R
+29 0x161D kvar export predicted sliding window demand 0-Pmax U3 UINT16 R
5056-5073 Total Energies
+0,1 0x1700
kWh import
0-999,999,999 1 kWh UINT32 R
+2,3 0x1701 kWh export 0-999,999,999 1 kWh UINT32 R
+4,5 Not used INT32 R
+6,7 Not used UINT32 R
+8,9 0x1704 kvarh import 0-999,999,999 1 kvarh UINT32 R
+10,11 0x1705 kvarh export 0-999,999,999 1 kvarh UINT32 R
+12,13 Not used INT32 R
+14,15 Not used UINT32 R
+16,17 0x1708 kVAh total 0-999,999,999 1 kVAh UINT32 R
5120-5137 Phase Energies
+0,1 0x1800
kWh import L1
0-999,999,999 1 kWh UINT32 R
+2,3 0x1801
kWh import L2
0-999,999,999 1 kWh UINT32 R
+4,5 0x1802
kWh import L3
0-999,999,999 1 kWh UINT32 R
+6,7 0x1803 kvarh import L1 0-999,999,999 1 kvarh UINT32 R
+8,9 0x1804 kvarh import L2 0-999,999,999 1 kvarh UINT32 R
